1. Port specifications:
Total Ports: 12 ports，
Copper Ports: 8 × 10/100/1000BASE-TX RJ45 (Twisted pair, max 100m)，
Fiber Slots: 4 × SFP slots (100/1000 Mbit/s, compatible with multimode/single mode SFP transceivers)，
Local management: USB-C port for configuration，
Digital Input: 1 × 2-pin plug-in terminal block，
Power Terminal: 1 x 6-pin plug-in terminal block (dual redundant power input).
2. Electrical power supply:
Input Voltage: Dual redundant 12–24 VDC，
Typical Power Consumption: 11 W，
Fanless design, no cooling fan
3. Environment and Machinery:
Mounting: DIN rail mounting，
Housing Material: PC-ABS plastic，
Protection Grade: IP30，
Standard model operating temp: 0 °C ~ +60 °C，
Extended EEC version: -40 °C ~ +70 °C，
Dimension (W×H×D): 73 × 138 × 115 mm，
Weight: 570 g，
MTBF: 3,119,057 hours
4. Software and Features:
Operating System: HiOS Layer 2 Standard，
Support TSN (Time-Sensitive Networking) for industrial real-time communication，
VLAN, IGMP Snooping v1/v2/v3, GVRP/GMRP, QoS/CoS, Storm Protection, Port Mirroring, Link Aggregation，
Redundant ring protocols: HIPER-Ring, MRP，
Diagnostic & status LED indicators for each port, power, fault
5. Certification compliance:
CE, FCC, cUL/UL 61010, EN 61131-2, EN 62368-1, RoHS3 compliant，
UNSPSC code: 55101515
6. Original material number:
Standard BRS40-8TX/4SFP: 942170009，
Wide temp variant BRS40-8TX/4SFP-EEC: 942170019
MANAGED INDUSTRIAL SWITCH; MODEL: BRS40-8TX/4SFP Specifications
| Total Ports | 12 ports， |
|---|---|
| Copper Ports | 8 × 10/100/1000BASE-TX RJ45 (Twisted pair, max 100m)， |
| Fiber Slots | 4 × SFP slots (100/1000 Mbit/s, compatible with multimode/single mode SFP transceivers)， |
| Local management | USB-C port for configuration， |
| Digital Input | 1 × 2-pin plug-in terminal block， |
| Power Terminal | 1 x 6-pin plug-in terminal block (dual redundant power input). |
| Input Voltage | Dual redundant 12–24 VDC， |
| Typical Power Consumption | 11 W， |
| Mounting | DIN rail mounting， |
| Housing Material | PC-ABS plastic， |
| Protection Grade | IP30， |
| Standard model operating temp | 0 °C ~ +60 °C， |
| Extended EEC version | -40 °C ~ +70 °C， |
| Dimension (W×H×D) | 73 × 138 × 115 mm， |
| Weight | 570 g， |
| MTBF | 3,119,057 hours |
| Operating System | HiOS Layer 2 Standard， |
| Redundant ring protocols | HIPER-Ring, MRP， |
| UNSPSC code | 55101515 |
| Standard BRS40-8TX/4SFP | 942170009， |
| Wide temp variant BRS40-8TX/4SFP-EEC | 942170019 |
About the MANAGED INDUSTRIAL SWITCH; MODEL: BRS40-8TX/4SFP
The MANAGED INDUSTRIAL SWITCH; MODEL: BRS40-8TX/4SFP is a electrical products used in industrial automation, control and power systems. It is rated at Total Ports 12 ports，, Copper Ports 8 × 10/100/1000BASE-TX RJ45 (Twisted pair, max 100m)，, Fiber Slots 4 × SFP slots (100/1000 Mbit/s, compatible with multimode/single mode SFP transceivers)，. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number MANAGED INDUSTRIAL SWITCH; MODEL: BRS40-8TX/4SFP for accurate procurement and cross-referencing.
Why source the MANAGED INDUSTRIAL SWITCH; MODEL: BRS40-8TX/4SFP from HDE123
- Verified part number: every MANAGED INDUSTRIAL SWITCH; MODEL: BRS40-8TX/4SFP is checked against its manufacturer specification before shipment.
- 21 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the MANAGED INDUSTRIAL SWITCH; MODEL: BRS40-8TX/4SFP
To order the MANAGED INDUSTRIAL SWITCH; MODEL: BRS40-8TX/4SFP, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
