1. Cross Reference Part Numbers
Russian factory drawing code: 2100-0240-О4 (standard mounting length)
Short version / short bellows variant: 2100S-0240-О4
Original EagleBurgmann OEM model: MG1-24/G6
Russian market trade marks (KIT / TorgVal): TM 2100-24 / R-2100-24
All codes are fully interchangeable, only mounting length differs between standard 2100 and short 2100S versions.
2. Material Combination (Cer/Car/NBR)
Rotating ring (rotor face): Carbon graphite (CAR / impregnated carbon)
Stationary seat (static face): Aluminium oxide ceramic (CER / Al₂O₃ ceramic)
Elastomer bellows: NBR nitrile rubber (for clean water, oil, mild neutral media)
Spring & metal components: Stainless steel G6 (SS304)
Stationary seat type: G6 fixed ceramic seat
3. Core Dimension (Shaft Size 24mm)
Shaft diameter d1: 24 mm
Outer diameter of stationary ring d3: 42.5 mm
Outer housing diameter d7: 39 mm
Standard total length MG1 (2100-0240-О4): 22.5 mm
Short version MG1S (2100S-0240-О4): shorter bellows overall length
Seat shoulder L1: 7.5 mm
4. Operating Technical Parameters
Max working pressure: ≤16 bar (1.6 MPa)
Temperature range: -20 ℃ ~ +120 ℃
Max sliding linear velocity: ≤10 m/s
Rotation direction: bidirectional (any rotation)
Structure: Single spring unbalanced elastomer bellows mechanical seal
Application: Centrifugal water pumps, circulation pumps, clean oil transfer pumps, industrial general fluid pumps
5. Weight & Packing
Net weight per complete set: 0.48 kg
Single carton gross weight: 0.62 kg
Package size: 65 × 65 × 30 mm
Mechanical Seal 2100-0240-О4 / 2100S-0240-О4 (MG1-24/G6 Cer/Car/NBR) Specifications
| Russian factory drawing code | 2100-0240-О4 (standard mounting length) |
|---|---|
| Short version / short bellows variant | 2100S-0240-О4 |
| Original EagleBurgmann OEM model | MG1-24/G6 |
| Rotating ring (rotor face) | Carbon graphite (CAR / impregnated carbon) |
| Stationary seat (static face) | Aluminium oxide ceramic (CER / Al₂O₃ ceramic) |
| Elastomer bellows | NBR nitrile rubber (for clean water, oil, mild neutral media) |
| Spring & metal components | Stainless steel G6 (SS304) |
| Stationary seat type | G6 fixed ceramic seat |
| Shaft diameter d1 | 24 mm |
| Outer diameter of stationary ring d3 | 42.5 mm |
| Outer housing diameter d7 | 39 mm |
| Standard total length MG1 (2100-0240-О4) | 22.5 mm |
| Short version MG1S (2100S-0240-О4) | shorter bellows overall length |
| Seat shoulder L1 | 7.5 mm |
| Max working pressure | ≤16 bar (1.6 MPa) |
| Temperature range | -20 ℃ ~ +120 ℃ |
| Max sliding linear velocity | ≤10 m/s |
| Rotation direction | bidirectional (any rotation) |
| Structure | Single spring unbalanced elastomer bellows mechanical seal |
| Application | Centrifugal water pumps, circulation pumps, clean oil transfer pumps, industrial general fluid pumps |
| Net weight per complete set | 0.48 kg |
| Single carton gross weight | 0.62 kg |
| Package size | 65 × 65 × 30 mm |
About the Mechanical Seal 2100-0240-О4 / 2100S-0240-О4 (MG1-24/G6 Cer/Car/NBR)
The Mechanical Seal 2100-0240-О4 / 2100S-0240-О4 (MG1-24/G6 Cer/Car/NBR) is a oil drilling equipment used in industrial automation, control and power systems. It is rated at Russian factory drawing code 2100-0240-О4 (standard mounting length), Short version / short bellows variant 2100S-0240-О4, Original EagleBurgmann OEM model MG1-24/G6. This oil drilling equipment is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number Mechanical Seal 2100-0240-О4 / 2100S-0240-О4 (MG1-24/G6 Cer/Car/NBR) for accurate procurement and cross-referencing.
Why source the Mechanical Seal 2100-0240-О4 / 2100S-0240-О4 (MG1-24/G6 Cer/Car/NBR) from HDE123
- Verified part number: every Mechanical Seal 2100-0240-О4 / 2100S-0240-О4 (MG1-24/G6 Cer/Car/NBR) is checked against its manufacturer specification before shipment.
- 23 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the Mechanical Seal 2100-0240-О4 / 2100S-0240-О4 (MG1-24/G6 Cer/Car/NBR)
To order the Mechanical Seal 2100-0240-О4 / 2100S-0240-О4 (MG1-24/G6 Cer/Car/NBR), add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
