2SC0435T2G1-17 Dual-Channel IGBT Driver Core
Brand: Power Integrations (CT Concept)
Model: 2SC0435T2G1-17；Code:2201（生产批次代码）
Product Name: SCALE™-2+ Dual Channel 1700V IGBT / MOSFET Gate Driver Core
Specifications
Channel: 2 independent channels
Supported device voltage class: Max 1700 V
Peak gate output current: ±35 A per channel
Gate driving voltage: +15 V / -10 V
Single channel max output power: 4 W
Input supply voltage: DC 14.5 ~ 15.5 V
Logic signal level: 5 V
Isolation: Reinforced galvanic isolation
Built-in protection: Short-circuit protection, Advanced Active Clamping, Under-voltage monitoring
Max switching frequency: 100 kHz
Dimension: 57.2 mm × 51.6 mm × 20 mm
Operating temperature: -40 ℃ ~ +85 ℃
Pin length: 3.1 mm (for 2mm PCB), enhanced EMC version, lead-free, non-conformal coated
Model: 2SC0435T2G1-17 Code: 2201 Specifications
| Brand | Power Integrations (CT Concept) |
|---|---|
| Model | 2SC0435T2G1-17；Code:2201（生产批次代码） |
| Product Name | SCALE™-2+ Dual Channel 1700V IGBT / MOSFET Gate Driver Core |
| Channel | 2 independent channels |
| Supported device voltage class | Max 1700 V |
| Peak gate output current | ±35 A per channel |
| Gate driving voltage | +15 V / -10 V |
| Single channel max output power | 4 W |
| Input supply voltage | DC 14.5 ~ 15.5 V |
| Logic signal level | 5 V |
| Isolation | Reinforced galvanic isolation |
| Built-in protection | Short-circuit protection, Advanced Active Clamping, Under-voltage monitoring |
| Max switching frequency | 100 kHz |
| Dimension | 57.2 mm × 51.6 mm × 20 mm |
| Operating temperature | -40 ℃ ~ +85 ℃ |
| Pin length | 3.1 mm (for 2mm PCB), enhanced EMC version, lead-free, non-conformal coated |
About the Model: 2SC0435T2G1-17 Code: 2201
The Power Integrations (CT Concept) Model: 2SC0435T2G1-17 Code: 2201 is a electrical products used in industrial automation, control and power systems. It is rated at Brand Power Integrations (CT Concept), Model 2SC0435T2G1-17；Code:2201（生产批次代码）, Product Name SCALE™-2+ Dual Channel 1700V IGBT / MOSFET Gate Driver Core. Manufactured by Power Integrations (CT Concept), this electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number Model: 2SC0435T2G1-17 Code: 2201 for accurate procurement and cross-referencing.
Why source the Model: 2SC0435T2G1-17 Code: 2201 from HDE123
- Verified part number: every Model: 2SC0435T2G1-17 Code: 2201 is checked against its manufacturer specification before shipment.
- 16 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the Model: 2SC0435T2G1-17 Code: 2201
To order the Power Integrations (CT Concept) Model: 2SC0435T2G1-17 Code: 2201, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
