ITEM SPECIFICATION
Product Name Hermetic Scroll Compressor
Brand DANFOSS Performer
Model SZ160T4RC
Application Chiller / Air Conditioning & Refrigeration
Approved Refrigerants R134a, R407C, R404A, R507A
Displacement 216.6 cm³/rev
Power Supply 380–415V/3Ph/50Hz；460V/3Ph/60Hz
Voltage Range 340~440V (50Hz)
Max Must Trip Current (MMT) 29 A
Locked Rotor Current (LRA) 150 A
Oil Type / Charge POE 160SZ / 4.0 L
Connection Type Rotolock
Max High Side Pressure 32 bar(g)
Max Low Side Pressure 25 bar(g)
Max starts per hour 12 times
Protection Internal thermostat (external overload required)
IP Rating IP54 (with cable gland)
Certification CE, UL
About the Model: SZ160T4RC Serial No: EK1106491656
The Model: SZ160T4RC Serial No: EK1106491656 is a air compressors used in industrial automation, control and power systems. This air compressors is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number Model: SZ160T4RC Serial No: EK1106491656 for accurate procurement and cross-referencing.
Why source the Model: SZ160T4RC Serial No: EK1106491656 from HDE123
- Verified part number: every Model: SZ160T4RC Serial No: EK1106491656 is checked against its manufacturer specification before shipment.
- 0 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the Model: SZ160T4RC Serial No: EK1106491656
To order the Model: SZ160T4RC Serial No: EK1106491656, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
