Basic information model: 6SY7010-6AA01
Product type: Siemens Masterdrives series dedicated heat sink thermistor (with UL certified circuit)
Core application: Masterdrives series frequency converters such as 6SE70 for power module/radiator temperature monitoring and overheating protection, applied in industrial transmission fields such as metallurgy, lifting, and papermaking
Adaptation equipment: SIMOVERT Masterdrives 6SE70 series frequency converter, power module, used for temperature signal acquisition of CUD control unit
Electrical parameter sensor type: NTC thermistor
Resistance value: 22k Ω (standard value at 25 ℃, typical value)
Temperature coefficient: in line with NTC standard characteristics, resistance decreases with increasing temperature
Rated voltage: 30V DC (signal level, compatible with control unit signal acquisition)
Rated current: ≤ 1mA (signal circuit, to avoid self heating affecting measurement accuracy)
Interface type: UL certified dedicated cable, compatible with 6SE70 frequency converter temperature signal interface
Signal output: Resistance signal, converted into temperature data by the control unit, used for overheating alarm and shutdown protection
Physical and environmental parameter structure form: mounted, suitable for surface installation of heat sinks
Cable length: The standard length is about 0.5m (suitable for internal wiring of frequency converters)
Protection level: IP00 (dependent on inverter cabinet protection)
Working temperature: -40 ℃ -125 ℃ (covering the working temperature range of the inverter radiator)
Storage temperature: -55 ℃ -150 ℃
Relative humidity: ≤ 85% (no condensation)
Weight: Approximately 0.01kg
Adaptation and functional adaptation components: 6SE70 series power module, radiator, CUD control unit
Functional features: Real time temperature monitoring, overheating alarm, fault shutdown triggering, ensuring safe operation of the inverter power module and extending equipment life
Installation requirements: Install on the surface of the radiator, connect the cable to the temperature signal interface of the control unit, fix reliably and avoid loosening
New original spare parts for 6SY7010-6AA01 DC speed regulator Specifications
| Basic information model | 6SY7010-6AA01 |
|---|---|
| Product type | Siemens Masterdrives series dedicated heat sink thermistor (with UL certified circuit) |
| Electrical parameter sensor type | NTC thermistor |
| Resistance value | 22k Ω (standard value at 25 ℃, typical value) |
| Temperature coefficient | in line with NTC standard characteristics, resistance decreases with increasing temperature |
| Rated voltage | 30V DC (signal level, compatible with control unit signal acquisition) |
| Rated current | ≤ 1mA (signal circuit, to avoid self heating affecting measurement accuracy) |
| Interface type | UL certified dedicated cable, compatible with 6SE70 frequency converter temperature signal interface |
| Cable length | The standard length is about 0.5m (suitable for internal wiring of frequency converters) |
| Protection level | IP00 (dependent on inverter cabinet protection) |
| Working temperature | -40 ℃ -125 ℃ (covering the working temperature range of the inverter radiator) |
| Storage temperature | -55 ℃ -150 ℃ |
| Relative humidity | ≤ 85% (no condensation) |
| Weight | Approximately 0.01kg |
About the New original spare parts for 6SY7010-6AA01 DC speed regulator
The New original spare parts for 6SY7010-6AA01 DC speed regulator is a oil drilling equipment used in industrial automation, control and power systems. It is rated at Basic information model 6SY7010-6AA01, Product type Siemens Masterdrives series dedicated heat sink thermistor (with UL certified circuit), Electrical parameter sensor type NTC thermistor. This oil drilling equipment is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number New original spare parts for 6SY7010-6AA01 DC speed regulator for accurate procurement and cross-referencing.
Why source the New original spare parts for 6SY7010-6AA01 DC speed regulator from HDE123
- Verified part number: every New original spare parts for 6SY7010-6AA01 DC speed regulator is checked against its manufacturer specification before shipment.
- 14 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the New original spare parts for 6SY7010-6AA01 DC speed regulator
To order the New original spare parts for 6SY7010-6AA01 DC speed regulator, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
