Model
NKI 85/26
Product Type
Single row machined ring needle roller bearing with inner ring and double flanged outer ring, interchangeable with NK95/26中国轴承工…
Specifications
Main Dimensions
Bore d: 85 mm
Outer diameter D: 115 mm
Bearing width B: 26 mm
Inner ring raceway diameter F: 95 mm
Min chamfer r₁,₂: 1 mm
Max allowable axial displacement s: 1.5 mmSKF 集…
Load Ratings (SKF standard)
Basic dynamic load rating Cr: 85 kN
Basic static load rating C0r: 146 kNSKF 集…
Speed Data
Grease reference speed: 4300 r/min
Oil limit speed: 4800 r/minSKF 集…
Material & Construction
Material: GCr15 bearing steel
Cage: Stamped steel sheet cage
Open type without integral seals; outer ring with lubrication groove & holes for relubrication
Two integrated flanges on outer ring to guide needle rollers axially
Features
Separable design: inner ring, needle roller assembly and outer ring can be mounted separately
Ultra-high radial load capacity, compact cross-section for limited radial installation space
Non-self-aligning; precise alignment between shaft and housing bore required
Application: Gearboxes, machine tool spindles, hydraulic pumps, heavy conveyor rollers, construction machinery
NKI 85/26 Specifications
| Bore d | 85 mm |
|---|---|
| Outer diameter D | 115 mm |
| Bearing width B | 26 mm |
| Inner ring raceway diameter F | 95 mm |
| Min chamfer r₁,₂ | 1 mm |
| Max allowable axial displacement s | 1.5 mmSKF 集... |
| Basic dynamic load rating Cr | 85 kN |
| Basic static load rating C0r | 146 kNSKF 集... |
| Grease reference speed | 4300 r/min |
| Oil limit speed | 4800 r/minSKF 集... |
| Material | GCr15 bearing steel |
| Cage | Stamped steel sheet cage |
| Separable design | inner ring, needle roller assembly and outer ring can be mounted separately |
| Application | Gearboxes, machine tool spindles, hydraulic pumps, heavy conveyor rollers, construction machinery |
About the NKI 85/26
The NKI 85/26 is a drive products used in industrial automation, control and power systems. It is rated at Bore d 85 mm, Outer diameter D 115 mm, Bearing width B 26 mm. This drive products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number NKI 85/26 for accurate procurement and cross-referencing.
Why source the NKI 85/26 from HDE123
- Verified part number: every NKI 85/26 is checked against its manufacturer specification before shipment.
- 14 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the NKI 85/26
To order the NKI 85/26, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
