Brand: Schneider‑Electric
Model: NSX160H 3P MA150F, Order‑code C16H3MA150 / LV430834
Product: ComPacT‑NSX series 3‑pole magnetic‑only moulded‑case circuit‑breaker for motor‑protection
Frame‑size:160 A, breaking‑capacity 70 kA @415 V‑AC
Pole‑spec:3‑Pole 3D, MA adjustable instantaneous‑magnetic trip‑unit, rated‑current 150 A
Instantaneous‑trip‑range:9‑14 times rated‑current
Rated‑operational‑voltage:690 V‑AC, 50‑60 Hz
Protection‑feature: Instantaneous short‑circuit magnetic‑trip, no overload‑delay
Connection: Fixed front‑mount screw‑type terminals
Mounting: DIN‑35 rail‑installation
Dimension:105mm × 161mm × 86mm
NSX160H/3P MA150F（150A）
Hde Shopping Event
Sale_coupon_15
$314.80
In stock
In stock
-
Pick up from the HDE Store
Located in:Xi'an City China
-
Courier delivery
Our courier will deliver to the specified address
- Courier delivery
DHL / Fedex / UPS / By Air
Payment Methods:
