Part No.: YZF2-250 (L1400)
Product Type: Float lever pointer oil level indicator for transformer conservator
Dial diameter: Φ250mm
Structure: YZF2 series, up-down swing float linkage structure, magnetic coupling transmission
Effective connecting rod length: 1400mm
Measuring range: Full scale 0~10 scale value (MIN ~ MAX oil level)
Accuracy class: 2.5 grade, indication & alarm error ≤ ±2.5% full scale
Switch function: Built-in high oil level / low oil level two groups alarm contact
Contact capacity: AC 1250VA(220V/1A); DC 125W(220V/0.3A)
Insulation strength: Withstand 2000V power frequency voltage for 1 minute without breakdown
Sealing performance: Shell withstand 245kPa pressure, no leakage for 20min
Protection grade: IP55
Working ambient temperature: -40℃ ~ +50℃
Allowable transformer oil temperature: -40℃ ~ +105℃
Ambient humidity: ≤95%RH (+20℃ environment)
Float material: Stainless steel floating ball; Shell: cast aluminum alloy
Installation mode: Flange fixed installation on transformer oil storage cabinet
Application: Real-time oil level display and over/under oil level alarm for power transformer conservator
OIL LEVEL GAUGE PART NO: YZF2-250 L1400, Specifications
| Part No | YZF2-250 (L1400) |
|---|---|
| Product Type | Float lever pointer oil level indicator for transformer conservator |
| Dial diameter | Φ250mm |
| Structure | YZF2 series, up-down swing float linkage structure, magnetic coupling transmission |
| Effective connecting rod length | 1400mm |
| Measuring range | Full scale 0~10 scale value (MIN ~ MAX oil level) |
| Accuracy class | 2.5 grade, indication & alarm error ≤ ±2.5% full scale |
| Switch function | Built-in high oil level / low oil level two groups alarm contact |
| Contact capacity | AC 1250VA(220V/1A); DC 125W(220V/0.3A) |
| Insulation strength | Withstand 2000V power frequency voltage for 1 minute without breakdown |
| Sealing performance | Shell withstand 245kPa pressure, no leakage for 20min |
| Protection grade | IP55 |
| Working ambient temperature | -40℃ ~ +50℃ |
| Allowable transformer oil temperature | -40℃ ~ +105℃ |
| Ambient humidity | ≤95%RH (+20℃ environment) |
| Float material | Stainless steel floating ball; Shell: cast aluminum alloy |
| Installation mode | Flange fixed installation on transformer oil storage cabinet |
| Application | Real-time oil level display and over/under oil level alarm for power transformer conservator |
About the OIL LEVEL GAUGE PART NO: YZF2-250 L1400,
The OIL LEVEL GAUGE PART NO: YZF2-250 L1400, is a instrumentation used in industrial automation, control and power systems. It is rated at Part No YZF2-250 (L1400), Product Type Float lever pointer oil level indicator for transformer conservator, Dial diameter Φ250mm. This instrumentation is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number OIL LEVEL GAUGE PART NO: YZF2-250 L1400, for accurate procurement and cross-referencing.
Why source the OIL LEVEL GAUGE PART NO: YZF2-250 L1400, from HDE123
- Verified part number: every OIL LEVEL GAUGE PART NO: YZF2-250 L1400, is checked against its manufacturer specification before shipment.
- 18 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the OIL LEVEL GAUGE PART NO: YZF2-250 L1400,
To order the OIL LEVEL GAUGE PART NO: YZF2-250 L1400,, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
