Basic information model: LUTM-UN81162P
Brand: SICK
Series: LUTM Fluorescence Sensor
Type: Compact Fluorescent Sensor
Light source: UV-LED, wavelength 370nm (average lifespan 100000h,+25 ℃)
Output type: NPN (light/dark switching optional)
Sensing distance: ≤ 12.5mm (starting from the front edge of the lens)
Spot size: 2mm × 2.5mm
Reception spectrum: 450nm – 750nm
Dimensions (width x height x depth): 12mm x 31.5mm x 21mm
Shell material: Plastic (ABS)
Electrical parameters Power supply voltage: 12-24VDC (12V-10%~24V+20%)
Residual ripple: ≤ 5Vds
Switching frequency: 6kHz (light/dark ratio 1:1)
Response time: 80 μ s (resistive load)
Output current: Maximum 100mA
Connection method: M12 4-pin male head, 0.2m cable
Teaching method: 2-point teaching (static/dynamic optional)
Mechanical and environmental parameters operating temperature: -10 ℃ to+55 ℃
Storage temperature: -20 ℃~+75 ℃
Relative humidity: 5% -95% (no condensation)
Protection level: IP67
Impact resistance: compliant with IEC 60068
Anti vibration: Complies with IEC 60068
Installation method: Embedded/Surface mounted
Functions and authentication features: light/dark switching, teaching button setting, LED status indication
Certification: CE, UL, RoHS, REACH
Original imported SICK fluorescence sensor LUTM-UN81162P from Germany Specifications
| Basic information model | LUTM-UN81162P |
|---|---|
| Brand | SICK |
| Series | LUTM Fluorescence Sensor |
| Type | Compact Fluorescent Sensor |
| Light source | UV-LED, wavelength 370nm (average lifespan 100000h,+25 ℃) |
| Output type | NPN (light/dark switching optional) |
| Sensing distance | ≤ 12.5mm (starting from the front edge of the lens) |
| Spot size | 2mm × 2.5mm |
| Reception spectrum | 450nm |
| Dimensions (width x height x depth) | 12mm x 31.5mm x 21mm |
| Shell material | Plastic (ABS) |
| Residual ripple | ≤ 5Vds |
| Switching frequency | 6kHz (light/dark ratio 1:1) |
| Response time | 80 μ s (resistive load) |
| Output current | Maximum 100mA |
| Connection method | M12 4-pin male head, 0.2m cable |
| Teaching method | 2-point teaching (static/dynamic optional) |
| Storage temperature | -20 ℃~+75 ℃ |
| Relative humidity | 5% -95% (no condensation) |
| Protection level | IP67 |
| Impact resistance | compliant with IEC 60068 |
| Anti vibration | Complies with IEC 60068 |
| Installation method | Embedded/Surface mounted |
| Functions and authentication features | light/dark switching, teaching button setting, LED status indication |
About the Original imported SICK fluorescence sensor LUTM-UN81162P from Germany
The SICK Original imported SICK fluorescence sensor LUTM-UN81162P from Germany is a oil drilling equipment used in industrial automation, control and power systems. It is rated at Basic information model LUTM-UN81162P, Brand SICK, Series LUTM Fluorescence Sensor. Manufactured by SICK, this oil drilling equipment is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number Original imported SICK fluorescence sensor LUTM-UN81162P from Germany for accurate procurement and cross-referencing.
Why source the Original imported SICK fluorescence sensor LUTM-UN81162P from Germany from HDE123
- Verified part number: every Original imported SICK fluorescence sensor LUTM-UN81162P from Germany is checked against its manufacturer specification before shipment.
- 24 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the Original imported SICK fluorescence sensor LUTM-UN81162P from Germany
To order the SICK Original imported SICK fluorescence sensor LUTM-UN81162P from Germany, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
