1. Model: SP10 2IN V220
2. IMPA material code: 591635
3. Product type: Pneumatic submersible bilge pump (pneumatic submersible pump, explosion-proof type)
4. Water outlet: 2 inches (50 mm)
5. Rated flow rate: 22 m ³/h
6. Rated head: 15 meters
7. Drive air source pressure: 0.5~0.7 MPa (5~7 bar)
8. Maximum gas consumption: 2.0 m ³/min
9. Inlet hose specification: 3/4 “(20mm)
10. Medium: bilge sewage, seawater/fresh water with a small amount of impurities, allowing for small solid particles
11. Explosion proof features: pure pneumatic drive, no electric spark, Ex explosion-proof, suitable for drainage in ship oil tanks and dangerous compartments
12. Shell material: cast iron (epoxy anti-corrosion coating), optional stainless steel version
13. Working medium temperature: 0~+60 ℃
14. Installation form: Submersible, handheld and portable structure
PNEUMATIC SUBMERSIBLE ELECTRIC PUMP, SP10 2IN V220, MFR:IMPA591635 Specifications
| 1. Model | SP10 2IN V220 |
|---|---|
| 2. IMPA material code | 591635 |
| 3. Product type | Pneumatic submersible bilge pump (pneumatic submersible pump, explosion-proof type) |
| 4. Water outlet | 2 inches (50 mm) |
| 5. Rated flow rate | 22 m ³/h |
| 6. Rated head | 15 meters |
| 7. Drive air source pressure | 0.5~0.7 MPa (5~7 bar) |
| 8. Maximum gas consumption | 2.0 m ³/min |
| 9. Inlet hose specification | 3/4 "(20mm) |
| 10. Medium | bilge sewage, seawater/fresh water with a small amount of impurities, allowing for small solid particles |
| 12. Shell material | cast iron (epoxy anti-corrosion coating), optional stainless steel version |
| 13. Working medium temperature | 0~+60 ℃ |
| 14. Installation form | Submersible, handheld and portable structure |
About the PNEUMATIC SUBMERSIBLE ELECTRIC PUMP, SP10 2IN V220, MFR:IMPA591635
The PNEUMATIC SUBMERSIBLE ELECTRIC PUMP, SP10 2IN V220, MFR:IMPA591635 is a drive products used in industrial automation, control and power systems. It is rated at 1. Model SP10 2IN V220, 2. IMPA material code 591635, 3. Product type Pneumatic submersible bilge pump (pneumatic submersible pump, explosion-proof type). This drive products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number PNEUMATIC SUBMERSIBLE ELECTRIC PUMP, SP10 2IN V220, MFR:IMPA591635 for accurate procurement and cross-referencing.
Why source the PNEUMATIC SUBMERSIBLE ELECTRIC PUMP, SP10 2IN V220, MFR:IMPA591635 from HDE123
- Verified part number: every PNEUMATIC SUBMERSIBLE ELECTRIC PUMP, SP10 2IN V220, MFR:IMPA591635 is checked against its manufacturer specification before shipment.
- 13 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the PNEUMATIC SUBMERSIBLE ELECTRIC PUMP, SP10 2IN V220, MFR:IMPA591635
To order the PNEUMATIC SUBMERSIBLE ELECTRIC PUMP, SP10 2IN V220, MFR:IMPA591635, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
