Model: S803S-K32 + S800-AUX
Brand: ABB (Switzerland)
Product Name: 3-pole high breaking capacity MCB + matching auxiliary contact module
Main breaker S803S-K32
Pole number: 3P
Rated current In: 32 A
Tripping characteristic: K curve, suitable for motor, transformer and inductive loads
Rated operating voltage: AC 400/690 V, DC 375 V
Ultimate breaking capacity at 415V AC: 50 kA
Protection mechanism: Thermal overload protection + electromagnetic short-circuit protection
Terminal form: Finger-proof screw terminals
Wiring specification: Solid wire up to 70 mm², flexible wire up to 50 mm²
Installation: 35mm standard DIN rail mounting
In-cabinet protection class: IP40
Auxiliary contact S800-AUX
Contact form: 1 normally open + 1 normally closed changeover contact
Maximum control voltage: AC 400 V / DC 250 V
Rated thermal current: 6 A
Installation way: Side snap-on assembly applicable to the whole S800 breaker series
Common technical parameters
Operating ambient temperature: -25 ℃ ~ +70 ℃
Mechanical service life: 20000 operating cycles
Electrical service life: 10000 operating cycles
Implementation standards: IEC 60947-2, IEC 60947-5-1, CE, UL, CSA, RoHS
S803S-K32+S800-AUX，ABB (Switzerland) Specifications
| Model | S803S-K32 + S800-AUX |
|---|---|
| Brand | ABB (Switzerland) |
| Product Name | 3-pole high breaking capacity MCB + matching auxiliary contact module |
| Pole number | 3P |
| Rated current In | 32 A |
| Tripping characteristic | K curve, suitable for motor, transformer and inductive loads |
| Rated operating voltage | AC 400/690 V, DC 375 V |
| Ultimate breaking capacity at 415V AC | 50 kA |
| Protection mechanism | Thermal overload protection + electromagnetic short-circuit protection |
| Terminal form | Finger-proof screw terminals |
| Wiring specification | Solid wire up to 70 mm², flexible wire up to 50 mm² |
| Installation | 35mm standard DIN rail mounting |
| In-cabinet protection class | IP40 |
| Contact form | 1 normally open + 1 normally closed changeover contact |
| Maximum control voltage | AC 400 V / DC 250 V |
| Rated thermal current | 6 A |
| Installation way | Side snap-on assembly applicable to the whole S800 breaker series |
| Operating ambient temperature | -25 ℃ ~ +70 ℃ |
| Mechanical service life | 20000 operating cycles |
| Electrical service life | 10000 operating cycles |
| Implementation standards | IEC 60947-2, IEC 60947-5-1, CE, UL, CSA, RoHS |
About the S803S-K32+S800-AUX，ABB (Switzerland)
The ABB (Switzerland) S803S-K32+S800-AUX，ABB (Switzerland) is a electrical products used in industrial automation, control and power systems. It is rated at Model S803S-K32 + S800-AUX, Brand ABB (Switzerland), Product Name 3-pole high breaking capacity MCB + matching auxiliary contact module. Manufactured by ABB (Switzerland), this electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number S803S-K32+S800-AUX，ABB (Switzerland) for accurate procurement and cross-referencing.
