SCANCON SCA24EX-360-AL-D-06-15-67-05-B-A-00
### Electrical
– Type：Incremental encoder
– Resolution：360 PPR
– Supply：5…24 VDC, max 35 mA (no load)
– Output：Differential (A, B, Z + complement A-,B-,Z-)
– Max frequency：200 kHz
– Output current：20 mA max per channel
– Reverse polarity & short-circuit protected
### Mechanical
– Housing / Cover：Aluminum
– Shaft：AISI 303 stainless steel, Ø6 mm
– Max continuous speed：3000 rpm
– Starting torque：＜0.001 Nm @25℃
– Max shaft load：Axial 10 N, Radial 10 N
– Moment of inertia：0.2 g·cm²
– Bearing life：＞1.9×10¹⁰ revolutions
### Environmental & Certification
– Enclosure：IP67
– Operating temp：-40 ℃ ~ +70 ℃
– Storage temp：-40 ℃ ~ +85 ℃
– Humidity：98% RH, non-condensing
– Shock：100 G / 11 ms；Vibration：10 G, 10–2000 Hz
– Cert：ATEX / IECEx Ex db IIC T5 Gb, Ex tb IIIC T100°C Db, Class I Div.2, Zone1 approved
