One Definition of Model Code:
1. Power supply voltage: DC 10-30V, fully protected against reverse connection, short circuit, and overload
2. Output type: PNP normally open NO, maximum load current 200mA
3. Rated detection distance Sn: 1.5mm, flush shielded installation
4. Switching frequency: 1000Hz
5. Static power consumption: ≤ 15mA
6. Implementation standards: IEC 60947-5-2, CE, cULus, UKCA, RoHS certification
II Key parameters of pressure resistance and environment (biggest highlight):
1. Maximum hydraulic pressure resistance: 500 bar (50MPa), can be directly screwed into the hydraulic cylinder chamber to detect the piston position
2. Protection level: IP68, long-term immersion in hydraulic oil, waterproof and dustproof
3. Working temperature: -25 ℃ to+80 ℃
4. Testing materials: magnetic conductive metals such as steel, iron, stainless steel, etc
3、 Mechanical dimensions and structure:
1. Thread specification: M12 × 1 metric fine thread
2. Overall size: Φ 12mm × total length 93mm
3. Installation method: flush embedded installation, can be fully screwed into the oil cylinder plug hole position
4. Shell material: 1.4104 stainless steel integrated pressure resistant shell
5. Outgoing interface: M12 4-core direct insertion aviation plug
6. Tightening torque: 20Nm
SENSOR BES516-300-S300-S4-D BALLUFF Specifications
| 1. Power supply voltage | DC 10-30V, fully protected against reverse connection, short circuit, and overload |
|---|---|
| 2. Output type | PNP normally open NO, maximum load current 200mA |
| 3. Rated detection distance Sn | 1.5mm, flush shielded installation |
| 4. Switching frequency | 1000Hz |
| 5. Static power consumption | ≤ 15mA |
| 6. Implementation standards | IEC 60947-5-2, CE, cULus, UKCA, RoHS certification |
| 1. Maximum hydraulic pressure resistance | 500 bar (50MPa), can be directly screwed into the hydraulic cylinder chamber to detect the piston position |
| 2. Protection level | IP68, long-term immersion in hydraulic oil, waterproof and dustproof |
| 3. Working temperature | -25 ℃ to+80 ℃ |
| 4. Testing materials | magnetic conductive metals such as steel, iron, stainless steel, etc |
| 1. Thread specification | M12 × 1 metric fine thread |
| 2. Overall size | Φ 12mm × total length 93mm |
| 3. Installation method | flush embedded installation, can be fully screwed into the oil cylinder plug hole position |
| 4. Shell material | 1.4104 stainless steel integrated pressure resistant shell |
| 5. Outgoing interface | M12 4-core direct insertion aviation plug |
| 6. Tightening torque | 20Nm |
About the SENSOR BES516-300-S300-S4-D BALLUFF
The SENSOR BES516-300-S300-S4-D BALLUFF is a electrical products used in industrial automation, control and power systems. It is rated at 1. Power supply voltage DC 10-30V, fully protected against reverse connection, short circuit, and overload, 2. Output type PNP normally open NO, maximum load current 200mA, 3. Rated detection distance Sn 1.5mm, flush shielded installation. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number SENSOR BES516-300-S300-S4-D BALLUFF for accurate procurement and cross-referencing.
Why source the SENSOR BES516-300-S300-S4-D BALLUFF from HDE123
- Verified part number: every SENSOR BES516-300-S300-S4-D BALLUFF is checked against its manufacturer specification before shipment.
- 16 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the SENSOR BES516-300-S300-S4-D BALLUFF
To order the SENSOR BES516-300-S300-S4-D BALLUFF, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
