SLP845-200KG Load Cell
Brand: METTLER TOLEDO
Model: SLP845-200KG, Cable length:3M, Accuracy class:C3/III S
Product Name: Hermetically Sealed Stainless Steel Single Point Load Cell
Specifications
Rated load: 200 kg
Cable length: 3 m
Accuracy class: C3 / III S
Maximum verification divisions (n): 5000
Minimum verification scale interval vmin: 50 g (0.1 lb)
Rated output: 2.0 mV/V
Excitation voltage: Recommended 5~12 VDC, Max 15 VDC
Zero balance: ±0.02 mV/V
Combined error: ≤±0.02 %FS
Creep (30 min): ≤±0.02 %FS
Material: Stainless steel, fully laser welded hermetic sealing
Protection class: IP68/IP69K
Max platform size: 500 × 400 mm
Operating temperature range: -10 ℃ ~ +40 ℃
SLP845-200KG 3M C3/III S n:5 vmin 50g/0.1lb Specifications
| Brand | METTLER TOLEDO |
|---|---|
| Model | SLP845-200KG, Cable length:3M, Accuracy class:C3/III S |
| Product Name | Hermetically Sealed Stainless Steel Single Point Load Cell |
| Rated load | 200 kg |
| Cable length | 3 m |
| Accuracy class | C3 / III S |
| Maximum verification divisions (n) | 5000 |
| Minimum verification scale interval vmin | 50 g (0.1 lb) |
| Rated output | 2.0 mV/V |
| Excitation voltage | Recommended 5~12 VDC, Max 15 VDC |
| Zero balance | ±0.02 mV/V |
| Combined error | ≤±0.02 %FS |
| Creep (30 min) | ≤±0.02 %FS |
| Material | Stainless steel, fully laser welded hermetic sealing |
| Protection class | IP68/IP69K |
| Max platform size | 500 × 400 mm |
| Operating temperature range | -10 ℃ ~ +40 ℃ |
About the SLP845-200KG 3M C3/III S n:5 vmin 50g/0.1lb
The METTLER TOLEDO SLP845-200KG 3M C3/III S n:5 vmin 50g/0.1lb is a instrumentation used in industrial automation, control and power systems. It is rated at Brand METTLER TOLEDO, Model SLP845-200KG, Cable length:3M, Accuracy class:C3/III S, Product Name Hermetically Sealed Stainless Steel Single Point Load Cell. Manufactured by METTLER TOLEDO, this instrumentation is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number SLP845-200KG 3M C3/III S n:5 vmin 50g/0.1lb for accurate procurement and cross-referencing.
Why source the SLP845-200KG 3M C3/III S n:5 vmin 50g/0.1lb from HDE123
- Verified part number: every SLP845-200KG 3M C3/III S n:5 vmin 50g/0.1lb is checked against its manufacturer specification before shipment.
- 17 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the SLP845-200KG 3M C3/III S n:5 vmin 50g/0.1lb
To order the METTLER TOLEDO SLP845-200KG 3M C3/III S n:5 vmin 50g/0.1lb, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
