– Brand: ABB, Series: Tmax XT2
– Poles: 3-pole, Fixed type, Front terminals (F F)
– Rated current In:20A; Frame size:160A
– Trip unit: TMD thermomagnetic release; overload fixed at 20A, instantaneous short circuit fixed at 300A
– Rated operational voltage Ue:690V AC, 50/60Hz; 500V DC
– Rated insulation voltage Ui:1000V
– Rated impulse withstand voltage Uimp:8kV
– Ultimate short-circuit breaking capacity Icu:36kA @400V AC
– Service short-circuit breaking capacity Ics:100% Icu
T2N160R20 XT2N160 TMD20-300 FF 3P
Hde Shopping Event
Sale_coupon_15
$95.82
1-2周
1-2周
-
Pick up from the HDE Store
Located in:Xi'an City China
-
Courier delivery
Our courier will deliver to the specified address
- Courier delivery
DHL / Fedex / UPS / By Air
Payment Methods:
