1. Basic information:
Device type: Light Triggered PCT Thyristor (formerly EUPEC Upac product line, now Infineon);
Brand: Infineon (Infineon, originally from Germany);
Packaging: Circular ceramic pressure bonded disc, diameter 150mm, thickness 40mm (DO-200AE standard packaging);
Suffix description: T=Light triggered type; The suffix ‘934’ is for original factory process/packaging matching, and the electrical core parameters are consistent with the T1503N80TOH reference model.
2. Temperature and thermal performance:
Junction temperature range: -40 ℃~+120 ℃ (maximum allowable junction temperature Tjmax=120 ℃);
Storage temperature: -55 ℃~+175 ℃;
Shell junction thermal resistance Rth (jc): about 0.04K/W (large diameter flat plate has strong heat dissipation advantages)
3. Structure and triggering characteristics:
Fiber optic trigger: Built in laser receiving window, no need for high-voltage isolation gate drive, no EMI electromagnetic interference risk;
Equipped with an integrated protection diode to suppress reverse overvoltage;
Sealed ceramic all metal shell, earthquake resistant, water pressure resistant, and no risk of shell bursting;
Supporting accessories: Special trigger laser diode SPL-PL90A, matching fiber LWL R10-LR87
4. Typical application scenarios:
HVDC converter valve for high-voltage direct current transmission;
High power electrolytic rectification (electrolytic aluminum, chlor alkali chemical industry);
High voltage static reactive power compensation SVC/STATCOM;
High power industrial DC drive, intermediate frequency power supply;
Large capacity soft start and fault current limiting device for power grid
THYRISTOR,Part No: T1503N80T-S34. Specifications
| Device type | Light Triggered PCT Thyristor (formerly EUPEC Upac product line, now Infineon) |
|---|---|
| Brand | Infineon (Infineon, originally from Germany) |
| Packaging | Circular ceramic pressure bonded disc, diameter 150mm, thickness 40mm (DO-200AE standard packaging) |
| Junction temperature range | -40 ℃~+120 ℃ (maximum allowable junction temperature Tjmax=120 ℃) |
| Storage temperature | -55 ℃~+175 ℃ |
| Fiber optic trigger | Built in laser receiving window, no need for high-voltage isolation gate drive, no EMI electromagnetic interference risk |
| Supporting accessories | Special trigger laser diode SPL-PL90A, matching fiber LWL R10-LR87 |
About the THYRISTOR,Part No: T1503N80T-S34.
The Infineon (Infineon, originally from Germany) THYRISTOR,Part No: T1503N80T-S34. is a electrical products used in industrial automation, control and power systems. It is rated at Device type Light Triggered PCT Thyristor (formerly EUPEC Upac product line, now Infineon), Brand Infineon (Infineon, originally from Germany), Packaging Circular ceramic pressure bonded disc, diameter 150mm, thickness 40mm (DO-200AE standard packaging). Manufactured by Infineon (Infineon, originally from Germany), this electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number THYRISTOR,Part No: T1503N80T-S34. for accurate procurement and cross-referencing.
Why source the THYRISTOR,Part No: T1503N80T-S34. from HDE123
- Verified part number: every THYRISTOR,Part No: T1503N80T-S34. is checked against its manufacturer specification before shipment.
- 7 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the THYRISTOR,Part No: T1503N80T-S34.
To order the Infineon (Infineon, originally from Germany) THYRISTOR,Part No: T1503N80T-S34., add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
