1. Product type: Traction Armature Assembly for DC Series Excitation Traction Motor
2. Compatible host: ZD109E diesel locomotive traction motor
3. Insulation level: H-grade
4. Armature type: laminated armature core, single wave winding, commutator structure
5. Cooling method: forced ventilation (with the main motor)
6. Applicable working conditions: locomotive traction, continuous working system
7. Material: Armature core: Cold rolled silicon steel sheet; Winding: Copper bar/enameled flat copper wire; Commutator: silver copper alloy; Axis: Alloy structural steel
8. Rated power of supporting machine: 530 kW
9. Rated voltage of the supporting machine: 670 V DC
10. Rated current of the supporting machine: 845 A
11. Rated speed of the supporting machine: 770 r/min
12. Maximum speed of the supporting machine: 2190 r/min
thirteen
13 Armature assembly (ZD13E-100-000) structural composition:
Armature shaft
Armature core laminations
Armature winding (flat copper wire)
Commutator (rectifier)
Armature binding ring/weftless band binding
Fan, balance block, bearing matching position
TRACTION ARMATURE ASSEMBLY，ZD13E-100-000 Specifications
| 1. Product type | Traction Armature Assembly for DC Series Excitation Traction Motor |
|---|---|
| 2. Compatible host | ZD109E diesel locomotive traction motor |
| 3. Insulation level | H-grade |
| 4. Armature type | laminated armature core, single wave winding, commutator structure |
| 5. Cooling method | forced ventilation (with the main motor) |
| 6. Applicable working conditions | locomotive traction, continuous working system |
| 8. Rated power of supporting machine | 530 kW |
About the TRACTION ARMATURE ASSEMBLY，ZD13E-100-000
The TRACTION ARMATURE ASSEMBLY，ZD13E-100-000 is a oil drilling equipment used in industrial automation, control and power systems. It is rated at 1. Product type Traction Armature Assembly for DC Series Excitation Traction Motor, 2. Compatible host ZD109E diesel locomotive traction motor, 3. Insulation level H-grade. This oil drilling equipment is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number TRACTION ARMATURE ASSEMBLY，ZD13E-100-000 for accurate procurement and cross-referencing.
Why source the TRACTION ARMATURE ASSEMBLY，ZD13E-100-000 from HDE123
- Verified part number: every TRACTION ARMATURE ASSEMBLY，ZD13E-100-000 is checked against its manufacturer specification before shipment.
- 7 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the TRACTION ARMATURE ASSEMBLY，ZD13E-100-000
To order the TRACTION ARMATURE ASSEMBLY，ZD13E-100-000, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
