1、 Core damping performance parameters:
Rated test speed: 0.1 m/s
Tensile damping force (0.1m/s): 4200 ± 420 N
Compressive damping force (0.1m/s): 3800 ± 380 N
Damping asymmetry: ≤ 10%
Effective working stroke: 110 mm
Ultimate total travel: 130 mm (anti-collision limit)
2、 Appearance and installation dimensions:
Minimum installation length (fully compressed): 325 mm
Maximum installation length (fully stretched): 435 mm
Cylinder outer diameter: 63 mm
Piston rod diameter: 18 mm
Installation form at both ends: Double ear rubber sleeve type
Installation hole diameter of liner inner hole: Ø 22 mm
Lining thickness: 12 mm
Center to installation hole width: 48 mm
3、 Material and Structure:
Cylinder barrel: 20 # seamless steel pipe, outer wall black epoxy spray, 500h salt spray rust prevention
Piston rod: 40Cr quenched and tempered+hard chrome polished, wear-resistant and corrosion-resistant
Sealing components: Fluororubber dust ring+oil seal, low temperature resistant, shock-absorbing hydraulic oil
Internal medium: Railway specific low-temperature damping hydraulic oil
Overall sealed structure, no leakage design
Vertical oil pressure damper，95000008 Specifications
| Rated test speed | 0.1 m/s |
|---|---|
| Tensile damping force (0.1m/s) | 4200 ± 420 N |
| Compressive damping force (0.1m/s) | 3800 ± 380 N |
| Damping asymmetry | ≤ 10% |
| Effective working stroke | 110 mm |
| Ultimate total travel | 130 mm (anti-collision limit) |
| Cylinder outer diameter | 63 mm |
| Piston rod diameter | 18 mm |
| Installation form at both ends | Double ear rubber sleeve type |
| Lining thickness | 12 mm |
| Center to installation hole width | 48 mm |
| Cylinder barrel | 20 # seamless steel pipe, outer wall black epoxy spray, 500h salt spray rust prevention |
| Piston rod | 40Cr quenched and tempered+hard chrome polished, wear-resistant and corrosion-resistant |
| Sealing components | Fluororubber dust ring+oil seal, low temperature resistant, shock-absorbing hydraulic oil |
| Internal medium | Railway specific low-temperature damping hydraulic oil |
About the Vertical oil pressure damper，95000008
The Vertical oil pressure damper，95000008 is a rail transit used in industrial automation, control and power systems. It is rated at Rated test speed 0.1 m/s, Tensile damping force (0.1m/s) 4200 ± 420 N, Compressive damping force (0.1m/s) 3800 ± 380 N. This rail transit is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number Vertical oil pressure damper，95000008 for accurate procurement and cross-referencing.
Why source the Vertical oil pressure damper，95000008 from HDE123
- Verified part number: every Vertical oil pressure damper，95000008 is checked against its manufacturer specification before shipment.
- 15 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the Vertical oil pressure damper，95000008
To order the Vertical oil pressure damper，95000008, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
