Valve form: direct acting, 2-position single electric control, 3-way seat valve medium: compressed air (not suitable for vacuum, VT307V for vacuum type), standard working pressure: 0-0.7 MPa, rated voltage: DC24V, allowable voltage fluctuation: -15%~+10%, power consumption: 1.8W (low-power coil), connecting pipe diameter: 1/4 “, Rc thread sealing material: HNBR (hydrogenated nitrile rubber, ozone resistant), temperature range: -10 ℃~+50 ℃ (medium, environment, no freezing allowed), response time ≤ 20ms (0.5MPa working condition), maximum operating frequency: 10 Hz, manual operation, no lock, press, manual button, lubrication, no need to supply oil; If lubrication is required, use ISO VG32 turbine oil protection level dustproof type outlet method G-type direct lead, installation direction can be installed in any direction
VT307-5G1-02
