YWF4D-500S External Rotor Axial Fan
Brand: Weiguang (Hangzhou Weiguang Electronics, China)
Model: YWF4D-500S
Product Name: 4-pole three-phase external rotor axial cooling fan, suction type
Specifications
Blade diameter: Φ500 mm
Power supply: 3~ AC 380V, 50Hz
Motor poles: 4 poles
Rated power: 414 W / 800 W (depends on sub-suffix 137/35 or 145/65)
Rated current: 0.85 A / 1.50 A
Rotating speed: 1300 ~ 1320 rpm
Air volume: 7000 ~ 9700 m³/h
Airflow type: S = suction type
Protection class: IP54
Insulation class: Class F
Working temperature: -30 ℃ ~ +60 ℃
Impeller: Steel / optional plastic blade
Overall outer dimension: Φ570 mm (with protective grill)
YWF4D-500S Specifications
| Brand | Weiguang (Hangzhou Weiguang Electronics, China) |
|---|---|
| Model | YWF4D-500S |
| Product Name | 4-pole three-phase external rotor axial cooling fan, suction type |
| Blade diameter | Φ500 mm |
| Power supply | 3~ AC 380V, 50Hz |
| Motor poles | 4 poles |
| Rated power | 414 W / 800 W (depends on sub-suffix 137/35 or 145/65) |
| Rated current | 0.85 A / 1.50 A |
| Rotating speed | 1300 ~ 1320 rpm |
| Air volume | 7000 ~ 9700 m³/h |
| Airflow type | S = suction type |
| Protection class | IP54 |
| Insulation class | Class F |
| Working temperature | -30 ℃ ~ +60 ℃ |
| Impeller | Steel / optional plastic blade |
| Overall outer dimension | Φ570 mm (with protective grill) |
About the YWF4D-500S
The Weiguang (Hangzhou Weiguang Electronics, China) YWF4D-500S is a drive products used in industrial automation, control and power systems. It is rated at Brand Weiguang (Hangzhou Weiguang Electronics, China), Model YWF4D-500S, Product Name 4-pole three-phase external rotor axial cooling fan, suction type. Manufactured by Weiguang (Hangzhou Weiguang Electronics, China), this drive products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number YWF4D-500S for accurate procurement and cross-referencing.
Why source the YWF4D-500S from HDE123
- Verified part number: every YWF4D-500S is checked against its manufacturer specification before shipment.
- 16 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the YWF4D-500S
To order the Weiguang (Hangzhou Weiguang Electronics, China) YWF4D-500S, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
