OMRON ZC-Q2255 Compact Enclosed Limit Switch
Brand: OMRON (Japan)
Model: ZC-Q2255
Product Name: Panel mount roller plunger enclosed limit switch
Core Specifications
Contact form: SPDT (1NO + 1NC, snap action)
Rated capacity: 10A, 250VAC
Actuator: Roller plunger with M14 threaded mounting
Protection grade: IP67
Connection: Screw terminal block
Operating force: Max 11.8 N
Pretravel: 1.5 mm; Overtravel: 3.0 mm
Mechanical life: ≥10,000,000 operations
Electrical life: ≥500,000 operations
Working temperature: -10 ℃ ~ +80 ℃
Housing material: Die-cast metal alloy
ZC-Q2255 Specifications
| Brand | OMRON (Japan) |
|---|---|
| Model | ZC-Q2255 |
| Product Name | Panel mount roller plunger enclosed limit switch |
| Contact form | SPDT (1NO + 1NC, snap action) |
| Rated capacity | 10A, 250VAC |
| Actuator | Roller plunger with M14 threaded mounting |
| Protection grade | IP67 |
| Connection | Screw terminal block |
| Operating force | Max 11.8 N |
| Pretravel | 1.5 mm; Overtravel: 3.0 mm |
| Mechanical life | ≥10,000,000 operations |
| Electrical life | ≥500,000 operations |
| Working temperature | -10 ℃ ~ +80 ℃ |
| Housing material | Die-cast metal alloy |
About the ZC-Q2255
The OMRON (Japan) ZC-Q2255 is a electrical products used in industrial automation, control and power systems. It is rated at Brand OMRON (Japan), Model ZC-Q2255, Product Name Panel mount roller plunger enclosed limit switch. Manufactured by OMRON (Japan), this electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number ZC-Q2255 for accurate procurement and cross-referencing.
Why source the ZC-Q2255 from HDE123
- Verified part number: every ZC-Q2255 is checked against its manufacturer specification before shipment.
- 14 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the ZC-Q2255
To order the OMRON (Japan) ZC-Q2255, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
