– Poles: 4-pole, all NO main contacts
– Rated AC-3 current: 38A @400V AC
– Rated AC-1 thermal current Ith:55A
– Rated main circuit voltage: 690V AC, 50/60Hz
– Coil voltage: Wide range 100~250V AC/DC
– Built-in surge suppression for coil
– Terminal: Screw terminal
– Mounting: 35mm DIN rail or panel mounting
– Protection class: IP20
– Mechanical life: 10 million cycles
– Electrical life: 1 million cycles under AC3 load
– Operating temperature: -25℃ ~ +70℃
AF38-40-00-13*100-250V Specifications
| Poles | 4-pole, all NO main contacts |
|---|---|
| Rated AC-3 current | 38A @400V AC |
| Rated AC-1 thermal current Ith | 55A |
| Rated main circuit voltage | 690V AC, 50/60Hz |
| Coil voltage | Wide range 100~250V AC/DC |
| Terminal | Screw terminal |
| Mounting | 35mm DIN rail or panel mounting |
| Protection class | IP20 |
| Mechanical life | 10 million cycles |
| Electrical life | 1 million cycles under AC3 load |
| Operating temperature | -25℃ ~ +70℃ |
About the AF38-40-00-13*100-250V
The AF38-40-00-13*100-250V is a electrical products used in industrial automation, control and power systems. It is rated at Poles 4-pole, all NO main contacts, Rated AC-3 current 38A @400V AC, Rated AC-1 thermal current Ith 55A. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number AF38-40-00-13*100-250V for accurate procurement and cross-referencing.
Why source the AF38-40-00-13*100-250V from HDE123
- Verified part number: every AF38-40-00-13*100-250V is checked against its manufacturer specification before shipment.
- 11 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the AF38-40-00-13*100-250V
To order the AF38-40-00-13*100-250V, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
