– Rated current In:4 A
– Tripping curve: C curve
– Rated operational voltage: 230/400V AC, 72V DC
– Ultimate short-circuit breaking capacity Icu:6kA @230V AC
– Rated insulation voltage Ui:440V
– Rated impulse withstand voltage Uimp:4kV
– Mounting: 35mm DIN rail installation
– Terminal: Screw terminal
– Protection class: IP20
– Mechanical life: 20,000 operating cycles
– Electrical life: 6,000 operating cycles
– Ambient temperature: -25℃ ~ +70℃
S201-C4 Specifications
| Rated current In | 4 A |
|---|---|
| Tripping curve | C curve |
| Rated operational voltage | 230/400V AC, 72V DC |
| Rated insulation voltage Ui | 440V |
| Rated impulse withstand voltage Uimp | 4kV |
| Mounting | 35mm DIN rail installation |
| Terminal | Screw terminal |
| Protection class | IP20 |
| Mechanical life | 20,000 operating cycles |
| Electrical life | 6,000 operating cycles |
| Ambient temperature | -25℃ ~ +70℃ |
About the S201-C4
The S201-C4 is a electrical products used in industrial automation, control and power systems. It is rated at Rated current In 4 A, Tripping curve C curve, Rated operational voltage 230/400V AC, 72V DC. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number S201-C4 for accurate procurement and cross-referencing.
Why source the S201-C4 from HDE123
- Verified part number: every S201-C4 is checked against its manufacturer specification before shipment.
- 11 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the S201-C4
To order the S201-C4, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
