Part No.: 900-23-2
Description: Gang release joystick
Brand: Barksdale, compatible with Series 9000 Shear-Seal manual directional hydraulic valve & valve cover 694-82-0, counterpart model 900-23-3 (standard mode joystick)
Model Functional Difference
900-23-3: Standard single detent joystick, only single circuit holding
900-23-2 Gang release: Interlinked multi-circuit release mechanism; all locked hydraulic circuits reset to neutral position simultaneously with one single pull, ideal for multi-cylinder synchronized fixture manifolds
Basic Hydraulic Specifications
Compatible valve: Barksdale Series 9000 2/3-position Shear-Seal manual directional valve
Max working pressure: 350 psi (24 bar) pilot control circuit
Compatible fluid: Standard anti-wear hydraulic oil, dry compressed air; not for water glycol fire-resistant fluids
Flow matching Cv factor: 0.75 for small & medium multi-circuit manifolds
Material & Mechanical Construction
Lever shaft: Solid carbon steel with black anti-rust finish
Grip knob: Oil-resistant black NBR rubber, anti-aging & slip-proof
Mount base: Die-cast hard anodized aluminum alloy
Core feature: Built-in gang release spring assembly for synchronous multi-position unlocking
Integrated dust boot seal to prevent contamination ingress into valve spool cavity
Direct bolt-on mounting for 694-82-0 valve cover assembly
Unit net weight: 0.19 kg
Key Features
Gang release function: One single operation resets all manifold circuits back to neutral, simplifies multi-station fixture operation
Auto spring return to neutral; mechanical lock at working positions for stable pressure holding
Split quick-disassemble design, joystick replacement without full manifold disassembly
Light operating torque for single-hand easy manipulation of multi-circuit systems
Environmental Ratings
Fluid temperature range: -20℃ ~ +80℃
Ambient operating temperature: -30℃ ~ +70℃
IP rating: IP54, suitable for hydraulic fixtures, stamping jigs, rescue multi-circuit hydraulic equipment
Max allowable fluid flow velocity: 20 ft/s
Barksdale 900-23-2 Gang release joystick Specifications
| Part No | 900-23-2 |
|---|---|
| Description | Gang release joystick |
| 900-23-3 | Standard single detent joystick, only single circuit holding |
| Compatible valve | Barksdale Series 9000 2/3-position Shear-Seal manual directional valve |
| Max working pressure | 350 psi (24 bar) pilot control circuit |
| Compatible fluid | Standard anti-wear hydraulic oil, dry compressed air; not for water glycol fire-resistant fluids |
| Flow matching Cv factor | 0.75 for small & medium multi-circuit manifolds |
| Lever shaft | Solid carbon steel with black anti-rust finish |
| Grip knob | Oil-resistant black NBR rubber, anti-aging & slip-proof |
| Mount base | Die-cast hard anodized aluminum alloy |
| Core feature | Built-in gang release spring assembly for synchronous multi-position unlocking |
| Unit net weight | 0.19 kg |
| Gang release function | One single operation resets all manifold circuits back to neutral, simplifies multi-station fixture operation |
| Fluid temperature range | -20℃ ~ +80℃ |
| Ambient operating temperature | -30℃ ~ +70℃ |
| IP rating | IP54, suitable for hydraulic fixtures, stamping jigs, rescue multi-circuit hydraulic equipment |
| Max allowable fluid flow velocity | 20 ft/s |
About the Barksdale 900-23-2 Gang release joystick
The Barksdale 900-23-2 Gang release joystick is a electrical products used in industrial automation, control and power systems. It is rated at Part No 900-23-2, Description Gang release joystick, 900-23-3 Standard single detent joystick, only single circuit holding. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number Barksdale 900-23-2 Gang release joystick for accurate procurement and cross-referencing.
Why source the Barksdale 900-23-2 Gang release joystick from HDE123
- Verified part number: every Barksdale 900-23-2 Gang release joystick is checked against its manufacturer specification before shipment.
- 17 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the Barksdale 900-23-2 Gang release joystick
To order the Barksdale 900-23-2 Gang release joystick, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
