1. Panel opening: * * 22mm**
2. Button type: Momentary, press to conduct, release to automatically reset
3. Lamp color: Blue LED indicator light
4. Contact module: ZB2-BE101C, * * 1NO normally open contact * *, screw terminal
5. Contact rating: 10A, AC15:240V/3A, Ui=600V
6. Installation base: ZB2-BZ21C, metal chrome plated installation ring, compatible with panel thickness of 1-6mm
7. Protection level: * * IP65 (front panel)**
8. Shell: Metal chrome frame, plastic button cap
9. Working environment temperature: * * -25 ℃~+70 ℃**
10. Function: Control cabinet start stop, signal indication, with blue LED status lighting
11. Dimensions: Φ 30 × 42.5mm (including base)
BLUE LIGHT BUTTON SWITCH, 22MM， PART NO. : ZB2-BWM+ZB2-BZ21C+ ZB2-BE101C Specifications
| 1. Panel opening | * * 22mm** |
|---|---|
| 2. Button type | Momentary, press to conduct, release to automatically reset |
| 3. Lamp color | Blue LED indicator light |
| 4. Contact module | ZB2-BE101C, * * 1NO normally open contact * *, screw terminal |
| 5. Contact rating | 10A, AC15:240V/3A, Ui=600V |
| 6. Installation base | ZB2-BZ21C, metal chrome plated installation ring, compatible with panel thickness of 1-6mm |
| 7. Protection level | * * IP65 (front panel)** |
| 8. Shell | Metal chrome frame, plastic button cap |
| 9. Working environment temperature | * * -25 ℃~+70 ℃** |
| 10. Function | Control cabinet start stop, signal indication, with blue LED status lighting |
| 11. Dimensions | Φ 30 × 42.5mm (including base) |
About the BLUE LIGHT BUTTON SWITCH, 22MM， PART NO. : ZB2-BWM+ZB2-BZ21C+ ZB2-BE101C
The BLUE LIGHT BUTTON SWITCH, 22MM， PART NO. : ZB2-BWM+ZB2-BZ21C+ ZB2-BE101C is a electrical products used in industrial automation, control and power systems. It is rated at 1. Panel opening * * 22mm**, 2. Button type Momentary, press to conduct, release to automatically reset, 3. Lamp color Blue LED indicator light. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number BLUE LIGHT BUTTON SWITCH, 22MM， PART NO. : ZB2-BWM+ZB2-BZ21C+ ZB2-BE101C for accurate procurement and cross-referencing.
Why source the BLUE LIGHT BUTTON SWITCH, 22MM， PART NO. : ZB2-BWM+ZB2-BZ21C+ ZB2-BE101C from HDE123
- Verified part number: every BLUE LIGHT BUTTON SWITCH, 22MM， PART NO. : ZB2-BWM+ZB2-BZ21C+ ZB2-BE101C is checked against its manufacturer specification before shipment.
- 11 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the BLUE LIGHT BUTTON SWITCH, 22MM， PART NO. : ZB2-BWM+ZB2-BZ21C+ ZB2-BE101C
To order the BLUE LIGHT BUTTON SWITCH, 22MM， PART NO. : ZB2-BWM+ZB2-BZ21C+ ZB2-BE101C, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
