1. Interface: * * 3/8 “NPT**
2. Medium: Compressed air
3. Maximum inlet pressure: * * 175 psi (12.1 bar)**
4. Pressure regulation output range: * * 0-125 psi (0-8.6 bar)**
5. Filtration accuracy: * * 40 μ m * *, polyethylene filter cartridge
6. Maximum flow: 60 SCFM
7. Pressure gauge interface: 2 × 1/8 “NPT
8. Valve body material: zinc alloy; Filter cup: polycarbonate transparent cup
9. Filter cup capacity: 3.8 oz
10. Adjustment method: manually adjust the pressure with a knob
11. Drainage: Manual drainage
12. Working temperature: * * -10 ℃~+60 ℃**
13. Modular structure, can be spliced with B75 series gas source components
14. Purpose: Pneumatic circuit air purification+stabilization, used for air source pretreatment of industrial equipment, pneumatic valves, and actuators
B75-03WJC NPT Filter Regulator Specifications
| 1. Interface | * * 3/8 "NPT** |
|---|---|
| 2. Medium | Compressed air |
| 3. Maximum inlet pressure | * * 175 psi (12.1 bar)** |
| 4. Pressure regulation output range | * * 0-125 psi (0-8.6 bar)** |
| 5. Filtration accuracy | * * 40 μ m * *, polyethylene filter cartridge |
| 6. Maximum flow | 60 SCFM |
| 7. Pressure gauge interface | 2 × 1/8 "NPT |
| 8. Valve body material | zinc alloy; Filter cup: polycarbonate transparent cup |
| 9. Filter cup capacity | 3.8 oz |
| 10. Adjustment method | manually adjust the pressure with a knob |
| 11. Drainage | Manual drainage |
| 12. Working temperature | * * -10 ℃~+60 ℃** |
About the B75-03WJC NPT Filter Regulator
The B75-03WJC NPT Filter Regulator is a electrical products used in industrial automation, control and power systems. It is rated at 1. Interface * * 3/8 "NPT**, 2. Medium Compressed air, 3. Maximum inlet pressure * * 175 psi (12.1 bar)**. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number B75-03WJC NPT Filter Regulator for accurate procurement and cross-referencing.
Why source the B75-03WJC NPT Filter Regulator from HDE123
- Verified part number: every B75-03WJC NPT Filter Regulator is checked against its manufacturer specification before shipment.
- 12 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the B75-03WJC NPT Filter Regulator
To order the B75-03WJC NPT Filter Regulator, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
