Honeywell DC1040 series 96×96mm panel PID temperature controller, Model DC1040CR-701000-E; Model code explanation: CR=RTD input, 7=3-position stepping motor valve output, 1=1 alarm relay, no communication, no remote setpoint, English manual; Power supply AC85~264V 50/60Hz, max power consumption 8VA; PV input compatible with PT100/JPT100 RTD, full range thermocouples (K/J/R/S/B/E/N/T), 0~10V / 4~20mA linear analog signal; Sampling time 250ms, 14-bit AD resolution, display accuracy ±0.5% full scale; Dual 4-digit 7-segment LED for PV process value & SP set value, auto PID tuning function; Main output: 3-position motor drive for gas/oil burner modulating valve, 1 SPDT alarm relay (3A/240VAC); Adjustable PID parameters: P band 0~200%, Integral 0~3600s, Derivative 0~900s, control cycle 0~150s adjustable; Overall dimension 96mm×96mm×94mm, panel cutout size 92mm×92mm; Front panel IP65 protection, flame retardant ABS housing; Operating ambient temp 0~50℃, storage -20~+65℃, humidity ≤85% RH non-condensing; E2PROM memory to retain parameters after power loss, CE certified, applied for closed-loop temperature control of boilers, heat treatment furnaces, ovens and fuel burners.
About the HoneywellDC1040CR-701000-E
The HoneywellDC1040CR-701000-E is a electrical products used in industrial automation, control and power systems. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number HoneywellDC1040CR-701000-E for accurate procurement and cross-referencing.
Why source the HoneywellDC1040CR-701000-E from HDE123
- Verified part number: every HoneywellDC1040CR-701000-E is checked against its manufacturer specification before shipment.
- 0 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the HoneywellDC1040CR-701000-E
To order the HoneywellDC1040CR-701000-E, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
