WEINVIEW TK6071IP

Weinview economical 7-inch industrial touch screen TK6071IP, equipped with 528MHz 32-bit ARM RISC CPU, 128MB Flash memory + 128MB DRAM; 7″ TFT LCD, resolution 800×480, 16 million colors, LED backlight lifespan ≥30,000 hours, brightness 350cd/㎡, contrast ratio 500:1; 4-wire analog resistive touch panel, touch accuracy ±2%; Interfaces: Micro USB 2.0 for program download, COM1 (RS232), COM2 (RS485 2W/4W), no Ethernet & USB Host; Wide power input DC10.5~28V, built-in power isolation, power consumption 300mA@24VDC / 550mA@12VDC, dielectric withstand voltage 500VAC for 1 minute, insulation resistance >50MΩ; Fanless natural cooling, front panel IP65/NEMA4 protection grade, ABS+PC plastic housing; Overall dimension W200.4×H146.5×D34mm, panel cutout size 192×138mm, panel mounting type; Operating temperature 0℃~50℃, storage -20℃~60℃, humidity 10%~90% RH non-condensing, vibration resistance 10~25Hz (X/Y/Z axis 2G for 30min); Built-in real-time clock, programming software EasyBuilder Pro V5.07+, compatible with Siemens, Mitsubishi, Omron, Delta, Modbus PLC series, CE certified, used for HMI control of assembly lines, fans, water pumps and small machine tools.
