1. Power supply voltage: * * DC24V**
2. Communication interface: * * 9-pin D-Sub (9-PIN CONNECTOR) PROFIBUS DP**
3. Protocol: PROFIBUS-DP slave station, switchable SIKONETZ3 protocol
4. Compatible device: SIKO AP09 position sensor
5. Maximum bus cable length: 200m
6. Isolation voltage: 500VDC
7. Installation method: DIN rail buckle installation
8. Shell: Engineering plastic
9. Protection level: * * IP20**
10. Status indicator lights: Power, Data Exchange LED indicator lights
11. Working temperature: -25 ℃~+70 ℃
12. Relative humidity: 10-90%, no condensation
13. Dimensions: Width 17.5 x Height 74 x Depth 61 mm
14. Function: Convert the SIKO position sensor signal into a PROFIBUS-DP bus signal and connect it to the PLC
IF09P/1-0001 devices INTERFACE MODULE 24VDC W/ 9-PIN CONNECTOR Specifications
| 1. Power supply voltage | * * DC24V** |
|---|---|
| 2. Communication interface | * * 9-pin D-Sub (9-PIN CONNECTOR) PROFIBUS DP** |
| 3. Protocol | PROFIBUS-DP slave station, switchable SIKONETZ3 protocol |
| 4. Compatible device | SIKO AP09 position sensor |
| 5. Maximum bus cable length | 200m |
| 6. Isolation voltage | 500VDC |
| 7. Installation method | DIN rail buckle installation |
| 8. Shell | Engineering plastic |
| 9. Protection level | * * IP20** |
| 10. Status indicator lights | Power, Data Exchange LED indicator lights |
| 11. Working temperature | -25 ℃~+70 ℃ |
| 12. Relative humidity | 10-90%, no condensation |
| 13. Dimensions | Width 17.5 x Height 74 x Depth 61 mm |
| 14. Function | Convert the SIKO position sensor signal into a PROFIBUS-DP bus signal and connect it to the PLC |
About the IF09P/1-0001 devices INTERFACE MODULE 24VDC W/ 9-PIN CONNECTOR
The IF09P/1-0001 devices INTERFACE MODULE 24VDC W/ 9-PIN CONNECTOR is a electrical products used in industrial automation, control and power systems. It is rated at 1. Power supply voltage * * DC24V**, 2. Communication interface * * 9-pin D-Sub (9-PIN CONNECTOR) PROFIBUS DP**, 3. Protocol PROFIBUS-DP slave station, switchable SIKONETZ3 protocol. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number IF09P/1-0001 devices INTERFACE MODULE 24VDC W/ 9-PIN CONNECTOR for accurate procurement and cross-referencing.
Why source the IF09P/1-0001 devices INTERFACE MODULE 24VDC W/ 9-PIN CONNECTOR from HDE123
- Verified part number: every IF09P/1-0001 devices INTERFACE MODULE 24VDC W/ 9-PIN CONNECTOR is checked against its manufacturer specification before shipment.
- 14 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the IF09P/1-0001 devices INTERFACE MODULE 24VDC W/ 9-PIN CONNECTOR
To order the IF09P/1-0001 devices INTERFACE MODULE 24VDC W/ 9-PIN CONNECTOR, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
