1. Rated detection distance: * * 2 mm * *, flush installation
2. Output type: * * DC two-wire system, normally open NO
3. Working voltage: * * 5-60 VDC**
4. Working current: 2~100mA, minimum working current 2mA
5. Switching frequency: 0-1000Hz
6. Voltage drop: ≤ 5V
7. Protection: Reverse polarity protection, pulse type short circuit protection
8. Indicator light: yellow LED status indicator
9. Shell: M12 cylindrical thread, nickel plated brass; Induction surface PBT material
10. Protection level: * * IP67**
11. Outgoing line: 2-meter gray PVC cable, 2-core, wire core 0.14mm ²
12 Dimensions: Diameter 12mm, Length 40mm
13. Working environment temperature: * * -40 ℃~+70 ℃**
SENSOR, NBB2-12GM40-Z0 Specifications
| 1. Rated detection distance | * * 2 mm * *, flush installation |
|---|---|
| 2. Output type | * * DC two-wire system, normally open NO |
| 3. Working voltage | * * 5-60 VDC** |
| 4. Working current | 2~100mA, minimum working current 2mA |
| 5. Switching frequency | 0-1000Hz |
| 6. Voltage drop | ≤ 5V |
| 7. Protection | Reverse polarity protection, pulse type short circuit protection |
| 8. Indicator light | yellow LED status indicator |
| 9. Shell | M12 cylindrical thread, nickel plated brass; Induction surface PBT material |
| 10. Protection level | * * IP67** |
| 11. Outgoing line | 2-meter gray PVC cable, 2-core, wire core 0.14mm ² |
| 12 Dimensions | Diameter 12mm, Length 40mm |
| 13. Working environment temperature | * * -40 ℃~+70 ℃** |
About the SENSOR, NBB2-12GM40-Z0
The SENSOR, NBB2-12GM40-Z0 is a electrical products used in industrial automation, control and power systems. It is rated at 1. Rated detection distance * * 2 mm * *, flush installation, 2. Output type * * DC two-wire system, normally open NO, 3. Working voltage * * 5-60 VDC**. This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number SENSOR, NBB2-12GM40-Z0 for accurate procurement and cross-referencing.
Why source the SENSOR, NBB2-12GM40-Z0 from HDE123
- Verified part number: every SENSOR, NBB2-12GM40-Z0 is checked against its manufacturer specification before shipment.
- 13 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the SENSOR, NBB2-12GM40-Z0
To order the SENSOR, NBB2-12GM40-Z0, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
