– Part No: **SI6000**
– Product: Calorimetric flow monitor / flow switch
– Measuring principle: Thermal calorimetric
– Probe length: 55 mm
– Measuring range:
– Liquid: **3 ~ 300 cm/s** (optimal 3~100 cm/s)
– Gas: **200 ~ 3000 cm/s** (optimal 200~800 cm/s)
– Electrical supply: **19…36 V DC**
– Output: 1 × PNP switching output, NO/NC configurable
– Max. switching current: 250 mA
– Medium temperature: **-25 … +80 °C**
– Process pressure: Max. **100 bar**
– Wetted material: Stainless steel 1.4404 (316L)
– Protection class: IP67
– Accuracy for water: Switch point tolerance ±2 ~ ±10 cm/s (5~100 cm/s, 25℃)
– Response time: 1 ~10 s
– Weight: **approx. 0.39 kg**
– Connection: M12 4-pin connector
– Feature: LED bar display for flow status, adjustable set point
– Application: Sanitary pipeline, pump dry-run protection, match with GEA VARIVENT valve, liquid & gas flow monitoring
IFM Flow sensor IFM SI6000 Specifications
| Part No | **SI6000** |
|---|---|
| Product | Calorimetric flow monitor / flow switch |
| Measuring principle | Thermal calorimetric |
| Probe length | 55 mm |
| Liquid | **3 ~ 300 cm/s** (optimal 3~100 cm/s) |
| Gas | **200 ~ 3000 cm/s** (optimal 200~800 cm/s) |
| Electrical supply | **19…36 V DC** |
| Output | 1 × PNP switching output, NO/NC configurable |
| Max. switching current | 250 mA |
| Medium temperature | **-25 … +80 °C** |
| Process pressure | Max. **100 bar** |
| Wetted material | Stainless steel 1.4404 (316L) |
| Protection class | IP67 |
| Accuracy for water | Switch point tolerance ±2 ~ ±10 cm/s (5~100 cm/s, 25℃) |
| Response time | 1 ~10 s |
| Weight | **approx. 0.39 kg** |
| Connection | M12 4-pin connector |
| Feature | LED bar display for flow status, adjustable set point |
| Application | Sanitary pipeline, pump dry-run protection, match with GEA VARIVENT valve, liquid & gas flow monitoring |
About the IFM Flow sensor IFM SI6000
The IFM Flow sensor IFM SI6000 is a instrumentation used in industrial automation, control and power systems. It is rated at Part No **SI6000**, Product Calorimetric flow monitor / flow switch, Measuring principle Thermal calorimetric. This instrumentation is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number IFM Flow sensor IFM SI6000 for accurate procurement and cross-referencing.
Why source the IFM Flow sensor IFM SI6000 from HDE123
- Verified part number: every IFM Flow sensor IFM SI6000 is checked against its manufacturer specification before shipment.
- 19 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the IFM Flow sensor IFM SI6000
To order the IFM Flow sensor IFM SI6000, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
