– Product: Flush hygienic pressure transmitter
– Part No: PM1717 (PM-1,6-REA01-E-ZVG/US)
– Measuring range: **-0.1 … 1.6 bar (-100 … 1600 mbar)**
– Output signal: **4…20 mA + IO-Link**
– Process connection: G1 external thread, Aseptoflex Vario hygienic connection
– Wetted material: 316L stainless steel (1.4435), 99.9% Al₂O₃ ceramic diaphragm, FKM seal
– Medium temperature: **-25 … +150 ℃ (max 1h SIP @150℃)**
– Supply voltage: 18…30 V DC
– Protection class: IP67 / IP69K
– Accuracy: 0.2 % FS
– Overload pressure: 15 bar; Burst pressure: 40 bar
– Dimension: Ø30.2 mm, Length = 111 mm
– Net weight: **0.308 kg (307.7 g)**
– Application: Food, beverage, pharmaceutical sanitary pipeline, CIP/SIP cleaning, viscous media & fluid with particles, matched with GEA VARIVENT valve
– Certifications: FDA, EC1935/2004, EHEDG
IFM Pressure sensor IFM PM1717 Specifications
| Product | Flush hygienic pressure transmitter |
|---|---|
| Part No | PM1717 (PM-1,6-REA01-E-ZVG/US) |
| Measuring range | **-0.1 … 1.6 bar (-100 … 1600 mbar)** |
| Output signal | **4…20 mA + IO-Link** |
| Process connection | G1 external thread, Aseptoflex Vario hygienic connection |
| Wetted material | 316L stainless steel (1.4435), 99.9% Al₂O₃ ceramic diaphragm, FKM seal |
| Medium temperature | **-25 … +150 ℃ (max 1h SIP @150℃)** |
| Supply voltage | 18…30 V DC |
| Protection class | IP67 / IP69K |
| Accuracy | 0.2 % FS |
| Overload pressure | 15 bar; Burst pressure: 40 bar |
| Dimension | Ø30.2 mm, Length = 111 mm |
| Net weight | **0.308 kg (307.7 g)** |
| Certifications | FDA, EC1935/2004, EHEDG |
About the IFM Pressure sensor IFM PM1717
The IFM Pressure sensor IFM PM1717 is a instrumentation used in industrial automation, control and power systems. It is rated at Product Flush hygienic pressure transmitter, Part No PM1717 (PM-1,6-REA01-E-ZVG/US), Measuring range **-0.1 … 1.6 bar (-100 … 1600 mbar)**. This instrumentation is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number IFM Pressure sensor IFM PM1717 for accurate procurement and cross-referencing.
Why source the IFM Pressure sensor IFM PM1717 from HDE123
- Verified part number: every IFM Pressure sensor IFM PM1717 is checked against its manufacturer specification before shipment.
- 14 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the IFM Pressure sensor IFM PM1717
To order the IFM Pressure sensor IFM PM1717, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
