Basic information model: SBG332
Brand: IFM (Yifumen)
Type: Liquid flow switch with check valve (flow sensor)
Detection principle: differential pressure type
Process connection: G1/2 internal thread (DN15)
Medium contact material: stainless steel 301/304 PBT、 Chemical nickel plated brass PP、PPS、 Polyolefin, FKM sealing ring
Dimensions: Approximately 40mm in width, 90mm in height, and 40mm in depth (excluding joints)
Protection level: IP65/IP67
Installation method: threaded installation, recommended for horizontal installation
Electrical parameters: Supply voltage: 10-30VDC (SELV/PELV)
Current consumption: ＜ 15mA
Output type: 1-channel PNP normally open (NO) switch output
Maximum output voltage drop: 2.5V
Maximum output current: 100mA
Protection functions: reverse polarity protection, short circuit protection, overload protection
Connection method: M12 4-pin plug
Insulation level: Level III
Measurement parameter measurement range: 1-15l/min
Setpoint: adjustable (within 1-15l/min)
Repetition accuracy: ± 1% of full scale
Response time:<0.01s
Medium temperature: 0-85 ℃
Working pressure: 40bar (4MPa)
Environment and certification working temperature: 0-60 ℃
Storage temperature: -15-80 ℃
Relative humidity: 10% -95% (no condensation)
Impact resistance: 20g (11ms, compliant with DIN EN 60068-2-27)
Anti vibration: 5g (10-2000Hz, in accordance with DIN EN 60068-2-6)
Certification: CE, UL, RoHS, EAC
IFM Yifumen Germany Original Flow Meter Sensor SBG332 Specifications
| Basic information model | SBG332 |
|---|---|
| Brand | IFM (Yifumen) |
| Type | Liquid flow switch with check valve (flow sensor) |
| Detection principle | differential pressure type |
| Process connection | G1/2 internal thread (DN15) |
| Medium contact material | stainless steel 301/304 PBT、 Chemical nickel plated brass PP、PPS、 Polyolefin, FKM sealing ring |
| Dimensions | Approximately 40mm in width, 90mm in height, and 40mm in depth (excluding joints) |
| Protection level | IP65/IP67 |
| Installation method | threaded installation, recommended for horizontal installation |
| Electrical parameters | Supply voltage: 10-30VDC (SELV/PELV) |
| Current consumption | |
| Output type | 1-channel PNP normally open (NO) switch output |
| Maximum output voltage drop | 2.5V |
| Maximum output current | 100mA |
| Protection functions | reverse polarity protection, short circuit protection, overload protection |
| Connection method | M12 4-pin plug |
| Insulation level | Level III |
| Measurement parameter measurement range | 1-15l/min |
| Setpoint | adjustable (within 1-15l/min) |
| Repetition accuracy | ± 1% of full scale |
| Response time | <0.01s |
| Medium temperature | 0-85 ℃ |
| Working pressure | 40bar (4MPa) |
| Storage temperature | -15-80 ℃ |
About the IFM Yifumen Germany Original Flow Meter Sensor SBG332
The IFM (Yifumen) IFM Yifumen Germany Original Flow Meter Sensor SBG332 is a oil drilling equipment used in industrial automation, control and power systems. It is rated at Basic information model SBG332, Brand IFM (Yifumen), Type Liquid flow switch with check valve (flow sensor). Manufactured by IFM (Yifumen), this oil drilling equipment is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number IFM Yifumen Germany Original Flow Meter Sensor SBG332 for accurate procurement and cross-referencing.
Why source the IFM Yifumen Germany Original Flow Meter Sensor SBG332 from HDE123
- Verified part number: every IFM Yifumen Germany Original Flow Meter Sensor SBG332 is checked against its manufacturer specification before shipment.
- 24 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the IFM Yifumen Germany Original Flow Meter Sensor SBG332
To order the IFM (Yifumen) IFM Yifumen Germany Original Flow Meter Sensor SBG332, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
