Basic information model: O5D102 (O5DLCNKG/US)
Brand: IFM Electronic
Type: Laser Ranging Displacement Sensor (Time of Flight Principle)
Laser grade: Class 2 (650nm visible red light)
Electrical connection: M12 4-pin plug
Installation method: 35mm DIN rail/screw installation
Protection level: IP67
Display/Operation: 3-digit alphanumeric display, 2 buttons+IO Link configuration
Size: 56 × 18.2 × 46.8mm
Weight: Approximately 84.8g
Shell material: PA shell, stainless steel front frame, TPU operation panel, PMMA lens
Electrical parameters Power supply voltage: 10-30V DC (SELV/PELV, current consumption 75mA at 24V)
Output configuration: 2-channel NPN digital output (NO/NC complementary, configurable)
Output current: Maximum 100mA per channel
Switching frequency: 11Hz
Short circuit/overload protection: pulse type short circuit protection, overload protection
Reverse protection: Yes
Insulation Class: Class III
Measurement parameter measurement range: 30-2000mm
Background suppression:<20m
Spot diameter:<5mm at 2m
Sampling rate: 33Hz
Detection lag:<2.5% range (black 6% reflectance)
Repetition accuracy: ± 3mm
Response time: 30ms
Working temperature: -25 ℃ to+60 ℃ (<-10 ℃ requires preheating)
Communication and Function IO Link: COM2 (38.4kBaud), Version 1.1
Configurable: switch point/hysteresis/delay/background suppression/display unit
Programming method: button or IO Link remote configuration
Environment and certification storage temperature: -40 ℃ to+85 ℃
Relative humidity: 5% -95% (no condensation)
Anti vibration: 10-55Hz, 0.15mm; 55–150Hz，5m/s²
Impact resistance: 15g (11ms)
Certification: CE, UL, CSA
Ifm Yifumen O5D102 laser ranging displacement sensor Specifications
| Basic information model | O5D102 (O5DLCNKG/US) |
|---|---|
| Brand | IFM Electronic |
| Type | Laser Ranging Displacement Sensor (Time of Flight Principle) |
| Laser grade | Class 2 (650nm visible red light) |
| Electrical connection | M12 4-pin plug |
| Installation method | 35mm DIN rail/screw installation |
| Protection level | IP67 |
| Display/Operation | 3-digit alphanumeric display, 2 buttons+IO Link configuration |
| Size | 56 × 18.2 × 46.8mm |
| Weight | Approximately 84.8g |
| Shell material | PA shell, stainless steel front frame, TPU operation panel, PMMA lens |
| Output configuration | 2-channel NPN digital output (NO/NC complementary, configurable) |
| Output current | Maximum 100mA per channel |
| Switching frequency | 11Hz |
| Short circuit/overload protection | pulse type short circuit protection, overload protection |
| Reverse protection | Yes |
| Insulation Class | Class III |
| Measurement parameter measurement range | 30-2000mm |
| Background suppression | <20m |
| Spot diameter | <5mm at 2m |
| Sampling rate | 33Hz |
| Detection lag | <2.5% range (black 6% reflectance) |
| Repetition accuracy | ± 3mm |
| Response time | 30ms |
About the Ifm Yifumen O5D102 laser ranging displacement sensor
The IFM Electronic Ifm Yifumen O5D102 laser ranging displacement sensor is a oil drilling equipment used in industrial automation, control and power systems. It is rated at Basic information model O5D102 (O5DLCNKG/US), Brand IFM Electronic, Type Laser Ranging Displacement Sensor (Time of Flight Principle). Manufactured by IFM Electronic, this oil drilling equipment is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number Ifm Yifumen O5D102 laser ranging displacement sensor for accurate procurement and cross-referencing.
Why source the Ifm Yifumen O5D102 laser ranging displacement sensor from HDE123
- Verified part number: every Ifm Yifumen O5D102 laser ranging displacement sensor is checked against its manufacturer specification before shipment.
- 24 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the Ifm Yifumen O5D102 laser ranging displacement sensor
To order the IFM Electronic Ifm Yifumen O5D102 laser ranging displacement sensor, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
