Inner bore diameter: φ160 mm, matched with d160 NBR reinforced piston GH3161-05.24.03.00(G)
Outer barrel outer diameter: φ200 mm; overall effective axial length: 422 mm
Structure: Integral centrifugal casting bimetallic liner, double annular sealing grooves machined on outer wall for liner O-ring static sealing
Single pump consumption: 3 pieces per full set of 3NB-1600F triplex mud pump
Matching pump core parameters: Rated stroke 305 mm, max stroke frequency 120 SPM, max discharge pressure 29.2 MPa
Positioning shoulder: Thickened outer step for interference fit into fluid end cylinder cavity
Liner d160 HTNB140.03.04.00 for pump 3NB-1600F Specifications
| Inner bore diameter | φ160 mm, matched with d160 NBR reinforced piston GH3161-05.24.03.00(G) |
|---|---|
| Outer barrel outer diameter | φ200 mm; overall effective axial length: 422 mm |
| Single pump consumption | 3 pieces per full set of 3NB-1600F triplex mud pump |
| Matching pump core parameters | Rated stroke 305 mm, max stroke frequency 120 SPM, max discharge pressure 29.2 MPa |
| Positioning shoulder | Thickened outer step for interference fit into fluid end cylinder cavity |
About the Liner d160 HTNB140.03.04.00 for pump 3NB-1600F
The Liner d160 HTNB140.03.04.00 for pump 3NB-1600F is a oil drilling equipment used in industrial automation, control and power systems. It is rated at Inner bore diameter φ160 mm, matched with d160 NBR reinforced piston GH3161-05.24.03.00(G), Outer barrel outer diameter φ200 mm; overall effective axial length: 422 mm, Single pump consumption 3 pieces per full set of 3NB-1600F triplex mud pump. This oil drilling equipment is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number Liner d160 HTNB140.03.04.00 for pump 3NB-1600F for accurate procurement and cross-referencing.
Why source the Liner d160 HTNB140.03.04.00 for pump 3NB-1600F from HDE123
- Verified part number: every Liner d160 HTNB140.03.04.00 for pump 3NB-1600F is checked against its manufacturer specification before shipment.
- 5 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the Liner d160 HTNB140.03.04.00 for pump 3NB-1600F
To order the Liner d160 HTNB140.03.04.00 for pump 3NB-1600F, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
