Nominal sealing outer diameter: φ160 mm, matched with D160 bimetal liner HTNB140.03.04.00
Central metal hub thread: M90×3 coarse thread, matches intermediate half-stem QF36001-04.11
Overall piston width: 76 mm; outer NBR composite sealing lip outer diameter φ164 mm
Structure: One-piece integrated bonded piston (42CrMo alloy steel core + NBR-PU composite outer sealing ring, non-detachable vulcanized bonding)
Single pump consumption: 3 pieces per complete set of 3NB-1600F triplex mud pump
Matching stroke: 305 mm (12 inch), max stroke frequency 120 SPM
Piston d160 GH3161-05.24.03.00(G) for pump NBR 3NB-1600F Specifications
| Nominal sealing outer diameter | φ160 mm, matched with D160 bimetal liner HTNB140.03.04.00 |
|---|---|
| Central metal hub thread | M90×3 coarse thread, matches intermediate half-stem QF36001-04.11 |
| Overall piston width | 76 mm; outer NBR composite sealing lip outer diameter φ164 mm |
| Single pump consumption | 3 pieces per complete set of 3NB-1600F triplex mud pump |
| Matching stroke | 305 mm (12 inch), max stroke frequency 120 SPM |
About the Piston d160 GH3161-05.24.03.00(G) for pump NBR 3NB-1600F
The Piston d160 GH3161-05.24.03.00(G) for pump NBR 3NB-1600F is a oil drilling equipment used in industrial automation, control and power systems. It is rated at Nominal sealing outer diameter φ160 mm, matched with D160 bimetal liner HTNB140.03.04.00, Central metal hub thread M90×3 coarse thread, matches intermediate half-stem QF36001-04.11, Overall piston width 76 mm; outer NBR composite sealing lip outer diameter φ164 mm. This oil drilling equipment is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number Piston d160 GH3161-05.24.03.00(G) for pump NBR 3NB-1600F for accurate procurement and cross-referencing.
Why source the Piston d160 GH3161-05.24.03.00(G) for pump NBR 3NB-1600F from HDE123
- Verified part number: every Piston d160 GH3161-05.24.03.00(G) for pump NBR 3NB-1600F is checked against its manufacturer specification before shipment.
- 5 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the Piston d160 GH3161-05.24.03.00(G) for pump NBR 3NB-1600F
To order the Piston d160 GH3161-05.24.03.00(G) for pump NBR 3NB-1600F, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
