Model: M/50/EAP/5U
Type: Magnetically operated solid state switch (solid-state electronic magnetic switch, non reed switch)
Output: PNP normally open NO Supply voltage: * * 10-30 V DC**
Cable length: * * 5 meters**
Cable specification: PUR 3 × 0.14 mm ²
Protection level: * * IP68 * * (U suffix represents IP68 waterproof, ordinary V suffix is IP67) IMI N
Equipped with LED status indicator light
Maximum load power: 3 W
Voltage drop:<2.5 V
Response time:<0.1 ms
Maximum switching frequency: 1 kHz
Action magnetic threshold: 2.8 mT
Hysteresis: 0.5-1.5 mT
Residual current:<0.5 mA
Operating Temperature
Cable fixed laying: -40 ℃~+80 ℃
Cable reciprocating motion: -25 ℃~+80 ℃ IMI N
Execution standards: EN 60947-5-2, EN 60529
M/50 magnetically operated solid state switch, 5m cable,M/50/EAP/5U
