1. Parameters
Rated input: 100-240 VAC, 50/60Hz
Input range: AC 85-264V/DC 80-370V
Maximum input current: 3.8A (AC100V)
Power factor: ≥ 0.9
2. Output parameters
Output voltage: 24 V DC
Rated power: 240 W
Rated output current: * * 10 A**
Voltage adjustable range: -10% to+15%
Ripple noise: ≤ 140 mV
-Protection: overcurrent protection (automatic reset), overvoltage protection
-Output hold time: approximately 64ms
3. Machinery and Environment
Installation method: DIN rail installation
Terminal: screw terminal
Working temperature: -10 ℃~+60 ℃
Storage temperature: -25 ℃~+65 ℃
Insulation withstand voltage: Input/output 3kVAC for 1 minute
