Detection principle: Triangular measurement method, background suppression type diffuse reflection photoelectric detection distance of 10… 80 mm (standard), maximum 100 mm; background suppression starting point: 100mm light source modulation red LED, no laser hazard (exempt group) power supply voltage: DC 10… 30 V output, 2-channel push-pull 4-in-1 output (configurable NPC/PNP, normally open/normally closed), supports IO Link single channel maximum output current of 100 mA switch frequency SIO mode: 1800Hz; IO Link mode: 900Hz response time SIO mode: 260 µ s; IO Link mode: 520 µ s electrical interface M8 4-pin male head (V31 plug) protection level IP67/IP69K environmental temperature -40 ℃~+60 ℃ shell material PC polycarbonate; Optical surface: Float glass standard EN60947-5-2, IEC61131-9 IO Link protection, reverse polarity protection, short circuit protection, overvoltage protection
OBT80-R102-2P1-IO-V31
Hde Shopping Event
Sale_coupon_15
$260.30
8-12weeks
