Material number P/N: R901523727 Installation form: Bottom plate installation, oil port standard ISO 4401-03-0-05 Maximum working pressure P, A, B ports: 350 bar; T oil return port: maximum 210 bar, rated flow rate of 16 L/min (pressure difference Δ p=10 bar), valve core function W-type (3-position 4-way, spring centered), power supply DC24V (allowable range 19.4~35V DC), control command signal ± 10V voltage signal/4~20mA current signal feedback, built-in LVDT valve core position, electrical feedback, sealing material FKM fluororubber (Viton), recommended hydraulic oil such as HL/HLP/HVLP, viscosity 2.8~500 mm ²/s, oil temperature -20 ℃~+80 ℃, interface, 7-pin aviation plug (6 cores+PE grounding) hysteresis ≤ 0.1%
R901523727- 4WREE6W16-30/V/24F1
Hde Shopping Event
Sale_coupon_15
$1,301.49
In stock
In stock
-
Pick up from the HDE Store
Located in:Xi'an City China
-
Courier delivery
Our courier will deliver to the specified address
- Courier delivery
DHL / Fedex / UPS / By Air
Payment Methods:
