Principal Technical Data
Accuracy: 2.5 Grade
Contact capacity：220V 1A AC; 220V 0.3A DC
Insulation Character: Terminal to earth: 2000vlmin, without break-down and corona
Sealing character: Withstand 245kpa pressure for 20min for YZF type without any leakage
Weight: Approximate 5kg
Working Condition
Operation temperature: -30℃~ 90℃
When the environment temperature is at 25℃±5℃, the relative humidity is not more 90%.
There is no serious pollution and corrosive medium in the atmosphere.
There is no violent vibration and turbulence around.
