-Model: DG50BG-6
-Adjustment range: * * 2.5-50 mbar (0.25-5 kPa)**
-Contact specifications: Single pole double throw conversion contact SPDT, * * 250VAC, 5A**
-Applicable medium: air (used in the primary air duct of the burner), can also be used for gas
-Action characteristics: pressure rise action, automatic reset
-Pressure interface: G1/4 external thread
-Electrical connection: 4-pin plug+matching socket (suffix -6 represents with socket, IP54)
-Protection level: IP54
-Membrane material: NBR silicone free nitrile rubber
-Shell: Die cast aluminum base+transparent scale cover
-Standard certification: EN1854 (Combustion Safety Standard)
Pressure Switch (for KL Primary Air Pipe Burner), Type: DG50BG-6, PN: 84447221, 2.5-50 mbar, 250VAC, 5A, Mat’l No. 80014791
Hde Shopping Event
Sale_coupon_15
$146.42
In stock
