1. Valve function: * * 5/2-way, monostable, gas reset
2. Valve width: 20mm
3. Power supply voltage: * * DC24V (18~30VDC)
4. Work pressure: * * -0.9~10 bar (supports vacuum)
5. Pilot pressure: 3-8 bar
6. Rated flow rate: * * 670 L/min (DIN1343)
7. Structure: piston slide valve, soft seal
8. Manual operation: Self resetting manual force button
9. Protection level: * * IP65 (after assembly)
10. Medium: Compressed air, compliant with ISO8573-1, can be lubricated with oil/without oil
11. Shell: Die cast aluminum alloy, NBR seal
12. Indicator light: with LED status display
13. Electrical interface: 4-pin M8 plug
14. Environmental temperature: * * -5 ℃~+50 ℃
15. Reversible flow direction, any installation position
16. Certification: cULus Recognized
17. Purpose: MPA series valve island, cylinder reversing control, pneumatic control for automated production lines
SOLENOID VALVE VMPA2-M1H-M #537952 Specifications
| 1. Valve function | * * 5/2-way, monostable, gas reset |
|---|---|
| 2. Valve width | 20mm |
| 3. Power supply voltage | * * DC24V (18~30VDC) |
| 4. Work pressure | * * -0.9~10 bar (supports vacuum) |
| 5. Pilot pressure | 3-8 bar |
| 6. Rated flow rate | * * 670 L/min (DIN1343) |
| 7. Structure | piston slide valve, soft seal |
| 8. Manual operation | Self resetting manual force button |
| 9. Protection level | * * IP65 (after assembly) |
| 10. Medium | Compressed air, compliant with ISO8573-1, can be lubricated with oil/without oil |
| 11. Shell | Die cast aluminum alloy, NBR seal |
| 12. Indicator light | with LED status display |
| 13. Electrical interface | 4-pin M8 plug |
| 14. Environmental temperature | * * -5 ℃~+50 ℃ |
| 16. Certification | cULus Recognized |
| 17. Purpose | MPA series valve island, cylinder reversing control, pneumatic control for automated production lines |
About the SOLENOID VALVE VMPA2-M1H-M #537952
The SOLENOID VALVE VMPA2-M1H-M #537952 is a electrical products used in industrial automation, control and power systems. It is rated at 1. Valve function * * 5/2-way, monostable, gas reset, 2. Valve width 20mm, 3. Power supply voltage * * DC24V (18~30VDC). This electrical products is supplied as new, original industrial-grade stock. Each unit is identified by manufacturer part number SOLENOID VALVE VMPA2-M1H-M #537952 for accurate procurement and cross-referencing.
Why source the SOLENOID VALVE VMPA2-M1H-M #537952 from HDE123
- Verified part number: every SOLENOID VALVE VMPA2-M1H-M #537952 is checked against its manufacturer specification before shipment.
- 16 confirmed technical parameters available on this page for engineering review.
- Global delivery with clear lead time and commercial invoice for B2B buyers.
- Fast B2B support: send us the equipment model or an existing part number and our engineers confirm compatibility before you order.
Ordering the SOLENOID VALVE VMPA2-M1H-M #537952
To order the SOLENOID VALVE VMPA2-M1H-M #537952, add it to your cart and complete checkout, or use the Request a Quote form for volume purchases and replacement / cross-reference enquiries. Lead time: typically 3–10 working days for in-stock items, subject to confirmation. Worldwide shipping is available and a commercial invoice is provided for customs.
