Yokogawa ZR202G-040-S-E-N-C-R-M-E-A Zirconia Oxygen Analyzer (Integral In-situ Type)
Description: Zirconia Oxygen Analyzer (Integrated In-situ)
Part No.: ZR202G-040-S-E-N-C-R-M-E-A
Brand: Yokogawa
Series: ZR202G
Probe Insertion Length: 0.4 m
Measuring Principle: Zirconia cell
Oxygen Measurement Range: 0.01 ~ 100 vol% O₂
User Setting Range: Adjustable from 0~5 up to 0~100 vol% O₂
Sample Gas Temp: 0 ~ 700 °C
Sample Gas Pressure: -5 ~ +250 kPa
Output: 4~20mA DC, Max load 550Ω; HART digital communication
Contact: 2 relay contact outputs (Fault / Alarm)
Power Supply: 100 ~ 240 VAC, 50/60Hz
Max Power Consumption: 330 VA
Probe Material: SUS316 stainless steel
Enclosure: Explosion-proof, Ex d IIB+H₂ T2, IP66
Warm-up Time: Approx. 20 minutes
Repeatability: ±0.5%FS (≤25%FS range), ±1%FS (>25%FS range)
Feature: Infrared local operation, field replaceable zirconia cell & heater
Application: Flue gas oxygen monitoring for MWM / Waukesha gas engine genset
